A pure-Rust, memory-safe, CPU-only OCR engine for a small family of hand-ported vision-language models. Baidu Unlimited-OCR is the fast default for document OCR, GOT-OCR2 handles specialized structured formats, SmolVLM2 handles image description and VQA, OneChart extracts chart data, and Polyphonic-TrOMR turns full scanned sheet-music pages or staff crops into MusicXML through --task music. All five runtime models are available through focr pull; TrOMR publishes both the 61 MB int8 default artifact and an 86 MB f32 reference artifact. The v0.7.0 Unlimited-OCR artifact uses the conservative exact recipe and passes the hard-page termination and complete 20-page corpus budget. The models run through model-specific Rust kernels and need no general ML framework, Python, CUDA, FFI at inference, or GPU.
curl -fsSL https://raw.githubusercontent.com/Dicklesworthstone/franken_ocr/main/install.sh | bashWindows (native, PowerShell):
irm https://raw.githubusercontent.com/Dicklesworthstone/franken_ocr/main/install.ps1 | iexThe installer detects your platform, resolves the latest published GitHub binary release (currently v0.8.0), verifies the downloaded asset by SHA256, and puts focr on your PATH. Install compatible model weights separately; after they are present, inference is offline.
v0.8.0 ships raw executables for macOS Apple Silicon, macOS Intel, Linux x86-64, Linux ARM64, Windows x86-64, and Windows ARM64, each with a SHA256 sidecar. Its embedded schema-v2 manifest continues to pin the v0.7.0 4,157,448,783-byte Unlimited-OCR artifact using recipe unlimited-ocr-ffn-int8-attn-bf16-lmhead-bf16-v1; focr pull verifies all three part hashes and the reassembled file before installation.
The exact-recipe artifact emits EOS on page0590 and passes the complete 20-page corpus budget at aggregate normalized CER 0.19307925. The release does not claim the strict three-party OpenPGP certificate: the committed fail-closed finalizer requires three independently controlled registry-pinned signers and production audit receipts, which are not available in this release process. The local corpus, model-census, installer, and binary checks are evidence, not a substitute for that governance claim.
The problem. Baidu Unlimited-OCR is a strong document-parsing model: Markdown, tables, LaTeX, reading order, many pages in one pass. The official stack is Python plus CUDA. Most machines that need OCR (laptops, CI runners, agent hosts, edge boxes) have no usable GPU, and a Python plus CUDA dependency is heavy to ship and awkward to embed.
The solution. franken_ocr is a library plus a single-binary CLI (focr) that runs the ready model set on CPU with nothing but a Rust binary. It transforms bf16 checkpoints into custom .focrq int8 artifacts and runs them through kernels written for each model's exact shapes. A historical real-page Unlimited-OCR run measured end-to-end character-error-rate 0.0094 and matched the reference decode to within a single token. The v0.7.0 corpus receipt records 20/20 pages within budget and a still-high page0590 tail; the release publishes that measured artifact without claiming the unavailable three-party signing certificate.
| Feature | What it does |
|---|---|
| One portable binary | No Python, no CUDA, no FFI at inference, no GPU. Current release assets are about 13 to 17 MB; portable to hosts where ort/CUDA cannot build. |
| Works offline | Once compatible weights are installed, inference never touches the network. Zoo pulls install under ~/.cache/franken_ocr/models; the v0.7.0 default is the versioned conservative Unlimited-OCR artifact. Weight bytes are owned by default; trusted immutable deployments can opt into mmap with FOCR_MMAP=1. |
| Embeddable Rust API | OcrEngine exposes synchronous, blocking calls for Markdown, structured layout, figure extraction, in-memory images, and load-once batches. |
| Native PDFs and figures | Scanned PDFs are rasterized in process with pure Rust; page /Rotate and image-placement rotations are honored, --pages selects exact PDF pages, --split-spreads can split two-page book scans, and --extract-figures saves chart/photo regions beside the Markdown or JSON output. |
| Cross-page parsing | --multi-page runs the Unlimited-OCR infer_multi contract over selected PDF pages, a directory of page images or an image list, producing one document with <PAGE> boundaries instead of unrelated page parses. |
| Model zoo with compatibility status | Ready engines: Unlimited-OCR, GOT-OCR2, SmolVLM2, OneChart, and Polyphonic-TrOMR, including full-page sheet-music OMR. focr models reports compatible and blocked pull entries with recipe metadata. All five runtime models are pullable in v0.7.0. Planned descriptors: TrOCR and pix2tex. |
| Measured int8 decode path | Historical rows show the custom int8 kernels can accelerate decoder work. The v0.7.0 exact-recipe artifact passes the hard-page termination and corpus-CER budget. Raw BF16 is only an all-high-precision native diagnostic when paired with FOCR_DECODE_STATELESS=1; the default cached decode applies the conservative int8 FFN/expert cache regardless of source storage. |
| Runtime ISA dispatch | One binary per architecture detects every available int8 ISA tier and reports the effective ordinary dense-GEMM route separately. Apple Silicon currently defaults to measured-faster LLVM autovec while retaining forced SDOT/SMMLA proof paths; x86 selects AVX-512-VNNI, AVX-VNNI, AVX2, or scalar. |
| Measured zoo gauntlet | docs/PERF_LEDGER.md records paired HF CPU reference rows. In the historical forced-Apple-SDOT rows at thread parity, decode-per-token ratios are 3.37x for GOT-OCR2, 2.58x for OneChart, and 1.67x for SmolVLM2; end-to-end rows are also kept, including slower cases. |
| Batch throughput path | focr ocr-batch loads weights once; the optional continuous-batch spine can prefill/decode multiple pages together while preserving per-page bytes. The dense zoo path covers GOT-OCR2, SmolVLM2, and OneChart with per-page token budgets. SAM, CLIP, and SigLIP towers plus their connector/embed tables are hydrated once, then reused across pages and batches. |
| Stage timing instrumentation | FOCR_TIMING=1 reports nested forward timings, including SAM hydrate/forward/block/attention/MLP splits, so perf work can separate artifact load, vision attention, decode, and output costs. |
| Durable run history | focr ocr records best-effort local telemetry in fsqlite; focr runs and focr sync expose the run log as plain text, JSON, NDJSON, or locked JSONL. |
| Bounded long-doc memory | R-SWA keeps generated-token KV constant (window 128) while the reference block is held as a frozen, never-evicted global KV. |
| Agent-first | Versioned NDJSON robot mode, a self-describing robot schema, one-shot robot triage, TrOMR staff and music_warning events for music runs, stable documented exit codes, deterministic output under fixed sampling. |
| Provable kernels | focr robot selftest re-runs the dispatched int8 GEMM against a bit-identical scalar oracle on your CPU, including per-model verdicts for Unlimited-OCR, GOT-OCR2, SmolVLM2, and OneChart. |
| Real-scan music gate | The TrOMR lane has public-domain Spohr page/staff fixtures, human-verifiable attributes, a frozen MusicXML anchor, and a model-gated NDJSON runner so real engraved scans are measured separately from synthetic examples. |
| Release evidence | scripts/ladder_scorecard.sh folds the L0-L5 parity ladder, docs/FEATURE_PARITY.md accounts the surface area, tests/property_suite.rs exercises generator-driven invariants, the committed fuzz corpus seeds four libFuzzer targets, scripts/bench_guardrail.py compares stage timings against frozen baselines, and scripts/gauntlet_cert.py computes the three-pillar scorecard, invariant monitors, and 13/13 release-readiness gate. |
| Memory-safe | #![forbid(unsafe_code)] everywhere except small audited islands: SIMD kernels with bit-identical scalar fallbacks, plus the explicitly opted-in read-only mmap loader. |
| Layer | What is live today |
|---|---|
| Inputs | PNG/JPG-style images, scanned PDFs, selected PDF page ranges, split book spreads, image batches, full sheet-music pages, and single staff crops. |
| Model routing | Unlimited-OCR for general documents, GOT-OCR2 for structured OCR modes, SmolVLM2 for describe/VQA, OneChart for chart data, and TrOMR for MusicXML. |
| Runtime core | OcrEngine owns one asupersync runtime, caches one model per process, exposes blocking Rust calls, and records best-effort run telemetry through fsqlite. |
| CPU execution | Fixed-shape Rust forwards call scalar-or-proven SIMD kernels. Apple Silicon advertises SDOT/SMMLA hardware but uses measured-faster LLVM autovec for ordinary dense int8 by default; Intel/AMD selects AVX-512-VNNI, AVX-VNNI, AVX2, or scalar. |
| Outputs | Markdown, structured JSON with layout boxes, cropped figure assets, MusicXML, versioned robot NDJSON, run-history JSON/NDJSON/JSONL, and release evidence artifacts. |
# 1. Install the versioned conservative Unlimited-OCR artifact.
focr pull
# 2. OCR a page into Markdown (the human default).
focr ocr page.png
# 3. Same page as structured JSON (markdown + every span's bounding boxes).
focr ocr page.png --json
# 4. Write the result to a file; format follows the extension (.md or .json).
focr ocr page.png -o page.md
focr ocr page.png -o page.json # structured JSON with bounding boxes
# 5. Also save figures the model can't transcribe (charts/photos) next to the .md.
focr ocr page.png -o page.md --extract-figures # -> page.md + page_figures/
# 6. Use a specialized model when the task is not plain document OCR.
focr pull got-ocr2
focr ocr --model got-ocr2.int8.focrq --task tables table.png
focr pull smolvlm2
focr ocr --model smolvlm2.int8.focrq --task describe photo.jpg
focr ocr --model smolvlm2.int8.focrq --task describe --question "How many people are visible?" photo.jpg
focr pull onechart
focr ocr --model onechart.int8.focrq --task chart-data chart.png
focr pull tromr
focr ocr --model tromr.int8.focrq --task music score-page-or-staff.png -o score.musicxml
focr pull tromr --quant f32 # bit-exact reference artifact when needed
focr ocr --model tromr.focrq --task music score-page-or-staff.png -o score.musicxml
# 7. OCR only the pages you need from a scanned PDF; optionally split two-page spreads.
focr ocr book.pdf --pages 3,5-9 --split-spreads -o excerpt.md
# 8. Stream NDJSON pipeline events for an agent (music runs also emit `staff` events).
focr ocr page.png --robot
focr robot triage
# 9. Prove the int8 kernels on THIS CPU are bit-identical to the scalar oracle.
focr robot selftest
# 10. Generate the parity-ladder and release-readiness scorecards used by release gates.
scripts/ladder_scorecard.sh --self-test
scripts/ladder_scorecard.sh --out scorecard.json
python3 scripts/gauntlet_cert.py --self-test
python3 scripts/bench_guardrail.py --self-test
python3 scripts/gauntlet_cert.py --from-parity docs/FEATURE_PARITY.md \
--scorecard-out /tmp/focr-release-scorecard.json
# From a clean final source/evidence commit, produce the red provisional bundle.
# It exits 1 until fresh CI artifacts and three trusted signers finalize it.
python3 scripts/gauntlet_cert.py --bundle .gauntlet-output/bundle
# After downloading the exact CI, dist, Model Parity, and Performance Gauntlet
# artifacts for this HEAD, run --finalize-bundle as documented in
# docs/gauntlet/RELEASE_CERTIFICATION_TEMPLATE.md.
python3 scripts/gauntlet_cert.py --release-readiness \
--readiness-out .gauntlet-output/release_readiness.json
# 11. (optional) Convert the exact pinned Unlimited-OCR bf16 shard.
# Same-shaped or reserialized inputs fail before an unloadable artifact is written.
focr convert model.safetensors -o unlimited-ocr.focrq --quant int8
# TrOMR conversion is available for local sheet-music artifacts.
focr convert /path/to/tromr/model.safetensors -o tromr.int8.focrq --quant int8 --model-id tromrWith FOCR_MODEL_PATH set, default-model inference runs fully offline. Compatible specialized pulls live under ~/.cache/franken_ocr/models and are also offline after installation.
A few models, every dimension fixed. A general ML framework pays a generality tax on every operation: dynamic dtype dispatch, arbitrary shapes, autograd bookkeeping, broadcast machinery, and a device abstraction. franken_ocr runs a small set of hand-ported models whose important dimensions are known up front. For the default Unlimited-OCR path that means hidden 1280, 10 heads, head_dim 128, 64 experts, top-6 routing, MoE intermediate 896, R-SWA window 128, and vocab 129280. That buys shape-specialized kernels with no runtime shape branching in the hot loop. The scope is a few hand-tuned, certified models, not any model; there is no generic runtime underneath.
Model status is explicit. focr models is the source of truth for the runtime zoo. Ready models have a runtime forward arm and can be used with focr ocr; planned models are visible so agents and humans can see the roadmap without accidentally running the wrong architecture. The table distinguishes runtime readiness from distribution compatibility. Unlimited-OCR, GOT-OCR2, SmolVLM2, OneChart, and TrOMR are pullable in v0.7.0. Non-primary models install into per-model cache subdirectories with their tokenizer sidecars beside the .focrq artifact. TrOMR publishes both int8 and f32 artifacts: the default pull is the smaller int8 artifact, while focr pull tromr --quant f32 restores the bit-exact reference path for audits.
Scanned books are addressable. PDF input no longer means "the whole document or nothing." --pages 3,5-9 selects source pages with 1-based ranges, reports out-of-range requests against the document page count, and keeps source page numbers in JSON/robot output. The native renderer applies both PDF page /Rotate metadata and the rotation implied by the image placement matrix, which fixes scanned-book files that store portrait page images but display them landscape through a rotated cm transform. --split-spreads is opt-in for common two-page book scans: a wide rasterized page with a near-blank center gutter becomes left and right logical pages, while pages without a qualifying gutter pass through unsplit.
TrOMR page OMR is resilient. TrOMR accepts either a staff crop or a full printed/scanned page. The page path runs pure-Rust staff detection with global deskew, trims horizontal page margins to the detected ink extent, grows wide staff bands toward neighbor midlines so they fit the model's 1280-column position budget where possible, orders crops top-to-bottom, recognizes each staff sequentially through the certified ResNetV2 plus ViT encoder and four-head decoder, merges the semantic streams, and emits partwise MusicXML. If a band is still too wide, setting FOCR_TROMR_SPLIT=1 arms an experimental rescue that detects thin full-span barlines, splits the band into in-budget segments, and splices the streams (off by default: isolated segments measurably lose absolute pitch registration, so this trades content fidelity for recognition coverage; the skip with a named reason is the honest default). If one detected staff fails, the page still succeeds with the staves that recognized and logs the skipped staff's bbox and reason; if every staff fails, the error names each staff reason. JSON output includes the ordered staves array for music runs, and robot mode emits one staff event for each recognized or skipped staff before run_complete. The MusicXML emitter also adds annotate-only sanity comments for overfull bars, underfull middle bars, impossible durations, and cross-staff key mismatches; JSON and robot mode expose the same observations as warnings and music_warning events. Remaining TrOMR work is narrower: optional **kern export, camera-photo dewarp, and broader corpus-quality metrics.
Performance claims are ledgered. The A11 zoo gauntlet records native runs beside pinned Hugging Face CPU references for GOT-OCR2, SmolVLM2, and OneChart. Decode-per-token speedups are documented where the native path is ahead, and full end-to-end rows stay in the ledger even when artifact loading or preprocessing makes the total slower. The CPU backend also records losing rows, such as the f32 TrOMR baseline, instead of turning them into marketing claims. The README summarizes measured rows; docs/PERF_LEDGER.md is the audit trail.
Offline at inference. Network access is limited to explicit compatible pull commands; inference itself never downloads. Raw BF16 or locally converted Unlimited weights can be supplied through FOCR_MODEL_PATH. There is no Python, no CUDA, no FFI, and no GPU in the inference path. The async runtime that orchestrates I/O and cancellation is an owned internal detail; the library API is synchronous and blocking, so there is no async plumbing to thread through your code.
Correctness before speed (always). A parity gate comes first and a faster kernel that drifts the OCR output is reverted, no source landed, and recorded in the negative-evidence ledger. Speed is shipped on top of parity, never instead of it. The conservative recipe keeps the vision tower, projector, embeddings, attention, lm_head, MoE router, and all norms high precision. The v0.7.0 artifact passes page0590 termination and the 20-page corpus budget, with the hard-page CER tail documented. Those measurements do not imply the separate three-party signing certificate.
Conformance has receipts. The L0-L5 parity ladder emits structured NDJSON, and scripts/ladder_scorecard.sh folds that stream into one focr-ladder-scorecard/v1 artifact. An unarmed no-weights run is recorded as skipped_no_model:true, never as green. docs/FEATURE_PARITY.md splits the release surface into the numbered FeatureUniverse and the CLI/robot SurfaceMatrix; tests/surface_matrix.rs fails if a live subcommand, robot event, exit code, or rollup cell is missing from that ledger. The three-pillar gauntlet in docs/gauntlet/METHODOLOGY.md and scripts/gauntlet_cert.py turns those rows into a franken_ocr.gauntlet.scorecard.v1 artifact, while the release ratchet compares lower bounds rather than point estimates. A change that improves the aggregate while lowering one category is blocked.
Runtime ISA dispatch, one binary per arch. There is no per-CPU-feature variant to choose. One x86_64 binary covers AVX2 / AVX-VNNI / AVX-512-VNNI; one aarch64 binary covers NEON / SDOT / SMMLA. Hardware capability and the effective ordinary dense-int8 route are distinct: Apple Silicon exposes SDOT/SMMLA, but measured decode results select the LLVM-autovectorized scalar loop by default. Forced SDOT and SMMLA remain available for parity and benchmark sweeps. Non-Apple ARM64 can select SMMLA when it is actually faster. On a Threadripper 5995WX, a Zen 3 part whose ceiling is AVX2, dispatch correctly selects AVX2.
Bounded generated-token KV. Every decoder attention layer is R-SWA (Reference Sliding Window Attention). Each generated token attends to all reference tokens (visual plus prompt prefix, kept as a frozen, never-evicted global KV) plus only the previous 128 generated tokens through a ring-buffer KV cache. Generated-token KV memory stays constant instead of growing with output length. That, not arbitrary input resolution, is what "Unlimited" means.
franken_ocr is the only one of these built for a fixed, hand-tuned set of models on CPU.
franken_ocr v0.8.0 |
Official Unlimited-OCR | llama.cpp | ONNX Runtime | |
|---|---|---|---|---|
| Language / runtime | Pure Rust, one binary | Python + HF transformers | C++ | C++ |
| Primary target | CPU | CUDA GPU | CPU/GPU | CPU/GPU |
| Scope | A few hand-tuned models | This model | Many models | Many models |
| int8 kernels | Model-specific tiled SDOT/SMMLA/VNNI | n/a | Generic K-quant | MLAS |
| Vision encoder | First-class, kept high precision | First-class | Kept F16 (mmproj) | Depends on export |
| Network at inference | None | None | None | None |
| Ships as | Single static binary, no FFI | Python env + CUDA | Binary + model | Library + model |
| Constant generated-token KV | Yes (R-SWA preserved) | Yes | Depends on PR support | Depends |
| Runs with no GPU | Yes | No (needs CUDA) | Yes | Yes |
When to use franken_ocr:
- You need this model's output and your host has no usable GPU.
- You want to embed OCR in a Rust program with no Python or FFI.
- You want one binary you can drop on a CI runner, an agent host, or an edge box.
When franken_ocr might not be ideal:
- You need a generic inference runtime that loads arbitrary models.
franken_ocrruns a few hand-ported, certified models by design. - You need the OmniDocBench leader; Unlimited-OCR is strong but not the top of the board.
curl -fsSL https://raw.githubusercontent.com/Dicklesworthstone/franken_ocr/main/install.sh | bashThe script detects your OS and CPU architecture, downloads the matching asset from the latest published binary release, verifies the SHA256 sidecar, and installs focr. At the time this source tag was cut, the latest published binary release was v0.8.0. Under WSL it proceeds as Linux. Under native Git-Bash, MSYS, or Cygwin it points you at the PowerShell installer below and exits cleanly.
On native Windows, install from PowerShell:
irm https://raw.githubusercontent.com/Dicklesworthstone/franken_ocr/main/install.ps1 | iexThis selects focr-x86_64-pc-windows-msvc.exe on AMD64 or focr-aarch64-pc-windows-msvc.exe on ARM64, verifies it by SHA256, and puts focr on your PATH. Both installers stage and execute the verified binary before an atomic replacement while holding a destination-scoped process lock, so a failed or concurrent update does not clobber a working install. Both Windows architectures are part of the v0.8.0 release matrix.
brew install dicklesworthstone/tap/focrThe formula installs the same SHA256-pinned release binary for your platform.
Release binaries are raw executables, not tar.gz archives. Each one is a single portable file that dispatches the ISA tier at runtime, so there is one binary per architecture (no per-CPU-feature variant). Linux assets are GNU binaries linked for glibc 2.17 or newer; the dist producer independently replays readelf against the exact staged bytes and refuses a higher required symbol version.
| Platform | Asset |
|---|---|
| macOS Apple Silicon | focr-aarch64-apple-darwin-neon-sdot-i8mm |
| macOS Intel | focr-x86_64-apple-darwin |
| Linux x86-64 (glibc 2.17+) | focr-x86_64-unknown-linux-gnu |
| Linux ARM64 (glibc 2.17+) | focr-aarch64-unknown-linux-gnu |
| Windows x86-64 | focr-x86_64-pc-windows-msvc.exe |
| Windows ARM64 | focr-aarch64-pc-windows-msvc.exe |
Each asset has a <asset>.sha256 sidecar in the standard "<hex> <asset>" format. Download the binary and its sidecar from the release base URL, verify, then install. Example for Apple Silicon:
base=https://github.com/Dicklesworthstone/franken_ocr/releases/download/v0.8.0
asset=focr-aarch64-apple-darwin-neon-sdot-i8mm
curl -fsSLO "$base/$asset"
curl -fsSLO "$base/$asset.sha256"
# macOS: shasum -a 256 -c | Linux: sha256sum -c
shasum -a 256 -c "$asset.sha256"
chmod +x "$asset"
mv "$asset" /usr/local/bin/focrOn Linux, swap the asset name and use sha256sum -c "$asset.sha256".
franken_ocr requires the nightly Rust toolchain pinned in rust-toolchain.toml. cargo build --locked --release builds both the focr and franken_ocr binaries from one shared entrypoint.
As of v0.8.0 the crate and its dependency closure (frankentorch-core,
frankentorch-kernel-cpu, the fsqlite family, asupersync) are published on
crates.io, so franken_ocr can be used as a library dependency. Two caveats:
the crate requires the pinned nightly toolchain on aarch64 (stdarch feature
gates in lib.rs), so cargo install franken_ocr fails on a stable default
toolchain there, and the registry build is not the byte-exact release binary.
Prebuilt binaries remain the supported install path. A source checkout
build still expects the sibling repositories (../asupersync,
../frankentorch, ../frankensqlite) laid out beside it (the workspace
path-deps win over the registry).
cargo build --locked --release
# produces target/release/focr and target/release/franken_ocr (identical behavior)- Install the binary with the curl one-liner, or download and verify a release asset by hand.
- Install compatible weights: run
focr pullfor the versioned conservative Unlimited-OCR artifact. Long documents can usefocr pull unlimited-ocr-2; specialized models usefocr pull got-ocr2,focr pull smolvlm2,focr pull onechart, orfocr pull tromr. Raw BF16 and locally converted exact-recipe artifacts remain available throughFOCR_MODEL_PATH. - Verify your CPU kernels (optional but reassuring):
focr robot selftest. Exit 0 means the dispatched int8 GEMM cases, including the model-specific rows for Unlimited-OCR, GOT-OCR2, SmolVLM2, and OneChart, are bit-identical to the scalar oracle on this host. - OCR a page:
focr ocr page.pngfor Markdown, add--jsonfor structured output (markdown + bounding boxes),-o out.md/-o out.jsonto write a file, or--robotfor an NDJSON event stream. - Batch many pages in one process (model loaded once):
focr ocr-batch page1.png page2.png page3.png --json. Add--multi-pageto parse them as ONE cross-referencing document instead of independent pages.
franken_ocr is a library as well as a CLI. The public API is synchronous and
blocking: OcrEngine owns the internal asupersync runtime, loads the model on
first use, caches that model behind an Arc, and returns ordinary
FocrResult<T> values. Callers do not need to build or pass an async runtime.
use std::path::Path;
use franken_ocr::{OcrEngine, FocrResult};
fn main() -> FocrResult<()> {
let engine = OcrEngine::new()?;
let markdown = engine.recognize(Path::new("page.png"))?;
println!("{markdown}");
let document = engine.recognize_with_layout(Path::new("page.png"))?;
println!("{} layout spans", document.layout.len());
Ok(())
}The same engine exposes the surfaces the CLI uses:
| Method | Use case |
|---|---|
recognize(path) |
Return Markdown for one image or document page. |
recognize_with_model(model, path) |
Pin a specific .focrq artifact without changing environment variables. |
recognize_with_layout(path) |
Return Markdown plus grounded bounding boxes, matching focr ocr --json. |
recognize_with_figures(path) |
Return Markdown/layout plus cropped figure regions, matching --extract-figures. |
recognize_dynamic(image) |
Run an already-decoded image::DynamicImage, the same in-memory path used by PDF rasterization. |
recognize_batch(&[paths]) |
Load weights once and return one result per input path, in order. |
recognize_document(model, source, &options, on_item, on_event) |
Parse a PDF, a directory or a list of pages as ONE cross-page document, matching --multi-page. The PageSource is read one page at a time; on_event streams each page as it ends, and each decode window (DocumentEvent). DocumentOptions picks the decode windows (Unlimited-OCR-2 reads windows of 10 pages by default; PageWindow::Off is one pass). The DocumentResult has the markdown, the pages, the skipped pages, the windows and the finish_reason. A document that stops early returns the pages it completed. |
recognize_pages(model, source, observer) |
Read a PageSource one page at a time, each page its own forward, matching focr ocr book.pdf. A failed page is skipped and reported to observer; a missing model or a cancel ends the walk. |
request_shutdown() / reset_shutdown() |
Drive cooperative cancellation for long-running embedders. |
OcrEngine belongs to the native feature. A program that wants the engine alone
links default-features = false, features = ["library"], which brings no CLI, async
runtime, run store, signal handler or network path, and calls OcrModel directly.
docs/library-output.md is its versioned contract: page and
span fields, box coordinates, reading order, side effects and what is not promised.
A document parse, using the pages of a PDF:
use std::path::Path;
use franken_ocr::page_source::PageSource;
use franken_ocr::{DocumentOptions, FocrResult, OcrEngine};
fn main() -> FocrResult<()> {
let engine = OcrEngine::new()?;
let source = PageSource::pdf(Path::new("book.pdf"))?.select(Some("1-20"))?;
let document = engine.recognize_document(
&OcrEngine::model_path(),
source,
&DocumentOptions::default(),
Box::new(|_| {}),
Some(Box::new(|page| eprintln!("page {} done", page.index))),
)?;
println!("{}", document.markdown);
eprintln!("{} pages, finish: {}", document.pages.len(), document.finish_reason.as_str());
Ok(())
}Model resolution follows the CLI rules: FOCR_MODEL_PATH wins, then the default
cache location is searched. For path-explicit calls, pass the model artifact
directly. The engine keeps the one-live-forward discipline from the CLI, so a
single process can reuse weights without fanning out concurrent model forwards.
Both focr ocr and focr robot run accept the same image plus inference-tuning flags. The default crop mode is base (the certified single 1024-pixel global view); --crop-mode gundam selects the reference dynamic-resolution tiling, whose end-to-end certification is still pending.
Parse a document image into Markdown (default), JSON, or an NDJSON stream.
focr ocr page.png # Markdown to stdout
focr ocr page.png --json # structured JSON to stdout
focr ocr page.png -o page.md # write Markdown to a file
focr ocr page.png -o page.json # write structured JSON (markdown + boxes) to a file
focr ocr page.png -o page.md --extract-figures # also save figures, referenced from the .md
focr ocr page.png --robot # NDJSON pipeline events
focr ocr page.png --crop-mode gundam # reference dynamic-resolution tiling (uncertified)
focr ocr page.png --max-length 4096 --temperature 0.0
focr ocr page.png --model /path/to/unlimited-ocr.focrq
focr ocr eq.png --task formula --model got-ocr2.int8.focrq # specialized task routing (see below)
focr ocr chart.png --task chart-data --model onechart.int8.focrq
focr ocr book.pdf --pages 3,5-9 --split-spreads -o excerpt.md
focr ocr ./scans/ --multi-page -o book.md # a directory of page images as one document
curl -s "$URL" | focr ocr - -o page.md # an image or a PDF on stdin
focr ocr book.pdf --multi-page --check # is this run ready? about a second, no weights loaded
focr ocr page.png --raw -o page.raw.txt # the model's output, grounding markers included
focr ocr page.png --threads 8 --timing # eight kernel threads, stage timings on stderrStdin (-). focr ocr - reads an image or a PDF from stdin, whichever the bytes
are. The run holds them in a private temp file and removes it when it ends. A file
actually named - is ./-. Empty stdin, or bytes that are neither, exits 4.
Preflight (--check). Runs the checks that can fail before a decode, then stops:
the arguments, the input's header or page list, --pages, the model's header and
tokenizer, and that -o has a directory to write into. It takes about a second on the
real artifacts, exits with the code the run would fail with, and records nothing in
focr runs. --json prints {command: "ocr.check", ok, input, model, output}. It
does not decode pixels, so a truncated image or a PDF page that will not rasterize
passes here and fails in the run. Use --json, not --robot, with it.
Output (-o/--output FILE). Writes the result to a file instead of stdout; the
format follows the extension: .json emits structured JSON, any other extension
(e.g. .md) emits Markdown. --json forces JSON regardless of extension. The
structured JSON carries the rendered markdown plus a layout array, one
{label, boxes} entry per grounded span, where each box is [x1, y1, x2, y2] in
source-image pixels. A span adds text, what the model wrote for that region: the
text after its marker, up to the next span, normalized as the markdown is. Image
spans have no text, and neither does a region the model boxed without writing
anything. An Unlimited-OCR-2 title adds its heading level (1, 2, …). A PDF nests these under a per-page pages array; split
spreads become separate logical page entries with the same source page number
and a "half": "left" or "right" marker. This is the same shape --json
prints to stdout. TrOMR music runs also include a staves array in source order;
each entry carries the 1-based staff number, page-space bbox, recognized or
skipped status, and an optional skip reason.
Raw output (--raw). Outputs the decode as the model wrote it, grounding markers
included: <|det|>label [x1, y1, x2, y2]<|/det|> spans (or the <|ref|> form), or
Unlimited-OCR-2's <BLOCK>label[x1, y1, x2, y2]<FORK> prefixes.
It replaces the markdown on stdout and in a text -o file. With JSON it adds a raw
string beside the markdown and to each entry of pages, and with --robot to
run_complete. Boxes stay on the model's 0–999 grid, relative to each page, or to
each strip of a tall image, so use layout for source-image pixels.
Figures (--extract-figures). The model sees figures/photos/diagrams it does not
transcribe to text. With --extract-figures, those regions are cropped out of the
source image and saved into a subfolder (default <output-stem>_figures/, or set
--figures-dir DIR), then referenced from the output: the Markdown gets a real
 in place of each figure, and the
JSON gains a figures array of {label, page, bbox, path}. Each figure's format is
chosen by content: JPG (quality 85) for photographic regions, lossless PNG for
line-art / charts / screenshots. Requires -o (or --figures-dir for a stdout run).
PDFs name figures per page (page{N}_figure_{M}); an Unlimited-OCR-2 document
with --split-spreads names a half's figures page{N}l_… / page{N}r_….
Directory input. focr ocr ./scans/ reads a directory of page images
(.png, .jpg, .jpeg, .tif, .tiff, .webp, .bmp, .gif, .pnm and
its variants) as one document, in natural order: p2.png comes before
p10.png. Each image's EXIF orientation is applied, as for a single image.
Hidden files and subdirectories are passed over. Any other file is left out
and reported once as an ignored_files warning (on stderr, run_complete and
--json). Everything below that applies to a PDF's pages applies to a
directory's images.
PDF controls. --pages SPEC is for PDFs and directories only. SPEC is a
comma-separated list of 1-based pages and inclusive ranges, such as 3, 3-7,
or 1,5-9,218; selected pages run in source order with duplicates removed.
Out-of-range pages are usage errors that name the document page count. Before
OCR, the pure-Rust PDF path applies both the page /Rotate entry and any
axis-aligned rotation from the content stream's image placement matrix, so scans
stored sideways but displayed upright are normalized before OCR or spread
splitting. --split-spreads is also off by default and applies only to
documents. It looks for wide raster pages with a near-blank vertical gutter
near the center, then OCRs the left and right halves as separate logical pages;
no qualifying gutter means the page remains unsplit. Pages are rasterized one
at a time as the run reaches them, so a long book never holds every page image
in memory.
Runaway pages (v1). A v1 page that never ends would decode to the token limit
(32,768) and come back mostly repetition. The runaway guard stops it instead: past
8,192 tokens it checks the last 2,048 every 256, and three repeating checks in a row
end the decode. The text before that point is written, the run reports
finish_reason: runaway and exits 5, and ocr-batch marks that image failed and goes
on. In robot mode the text arrives as page events (status: decoded) before the
run_error. FOCR_RUNAWAY_GUARD=0 turns it off and decodes to the limit, as the reference
does. On ground truth it fires on no OmniDocBench page and on 9 of 18,118
MarathonDocBench pages, 7 with broken references and 2 long charts (DISC-023).
Multi-page cross-page parsing (--multi-page). By default every page is
parsed independently. --multi-page instead parses the whole document across
pages using the Unlimited-OCR infer_multi contract, so page N can reference
content on the pages before it, and the output is a single Markdown document with
<PAGE> separators. On focr ocr it takes a PDF or a directory of page
images and composes with --pages; for an image list use focr ocr-batch page1.png page2.png --multi-page. v1 has
32,768 positions shared by prompt and output (≈29 dense pages); longer documents
stop early and report finish_reason: length with a v1_truncated warning (a
prompt that alone exceeds the budget fails with an actionable error). When v1
ends with fewer page bodies than pages, a v1_page_merge warning says the page
boundaries are unreliable; with more bodies than pages, a v1_extra_pages
warning says it repeated or invented pages. On v1 it does not compose with --split-spreads or
--extract-figures (per-page semantics), and --json lists real pages[] only
when the text has exactly one body per page (otherwise pages: []).
--page-window N|auto|off sets how unlimited-ocr-2 splits a --multi-page
document into decode windows. N is pages per window, at most 102, and the
default is 10. auto picks the largest window, up to 10, whose estimated
whole-process memory fits FOCR_MEMORY_BUDGET, and refuses with the estimate's
parts when not even one page fits. off reads one pass with no checkpoint, so
a long document can stop at the position limit with its pages written and exit 5.
Robot mode reports a window event after each window's pages, and a terminal
shows pages and windows done, tokens per second and an estimate of the time left.
Unlimited-OCR-2 (--model unlimited-ocr-2) emits exactly one <PAGE> per page,
so its document mode has real pages. A document of more than 10 pages is read
in windows of 10: each window's prompt holds its own pages and the next
window's first, a page sees the pages before it in its window, and memory stays
bounded at any length. A window that stops early ends the document with its
completed pages. --json lists one pages[] entry per page
read: page (the source page), half on a split spread, run_index, window
when windowed, text, layout (boxes in that page's own pixels), tokens and
finish (marker, eos, page_cap, runaway, length, budget or cancelled), and raw under --raw. A
v2_page_cap warning lists any page the per-page cap (--max-page-tokens, default 20,000)
closed, which is almost always a runaway. FOCR_RUNAWAY_GUARD=1 (off by default here) closes such
a page sooner: once a page passes 8,192 tokens and its last 2,048 repeat (any number counts as
the same token, so a counting loop repeats too), the next page opens. The page ends runaway,
keeps its text so far, and is listed in the same warning. With FOCR_REREAD_CAPPED_PAGES=1 (off by
default), each such page is read again alone once the document is decoded. The re-read
replaces the page when the model ends it, and a v2_page_reread warning lists the pages
replaced and the pages kept. Robot page events are not sent again. Document mode composes with --split-spreads
(each half is one page of the prompt) and with --extract-figures: figures are
cropped from their page after the decode and named page{N}_figure_{M}, or
page{N}l_figure_{M} / page{N}r_figure_{M} on a half. Robot page events add
source_page, half, model_id, and for decoded pages tokens, finish,
window (null in one pass) and, for a page read in one pass, elapsed_ms.
Stopping and resuming a long document. After each window, a windowed
Unlimited-OCR-2 run appends its pages to a journal and replaces a checkpoint:
<out>.partial and <out>.focr-ckpt beside -o, or
~/.cache/franken_ocr/document-runs/<key>/ when the output goes to stdout.
Ctrl+C or a spent stage budget writes the completed pages and exits 6 or 5, and
the terminal run_error names the checkpoint. Re-running the same command
(--resume says so explicitly) continues from the last completed window, and
the result is byte-identical to an uninterrupted run; resumed_from on the
terminal event gives the page decoding restarted at, and a stdout run prints the
whole document again. The pages of a window that was interrupted are decoded
again. A run whose input, page selection or decode settings differ is refused,
with the fields named. --resume=recompute then keeps the completed pages and
recomputes the next window: the pages after it can differ, so a
resume_recompute warning says so. Both files are removed when the document
finishes (--keep-checkpoint keeps the checkpoint), and focr doctor lists a
stale stdout run with the command that continues it.
Tall captures (full-page screenshots). A full-page browser capture (e.g. the
Awesome Screenshot extension) is one extremely tall image — 1:4 to 1:10 aspect.
A single model pass over such an image squashes glyphs below legibility and used
to come back near-empty with exit 0. Two things now happen instead. First,
single images with height ≥ 3× width are automatically OCR'd as smart-cut
horizontal strips (each cut lands on the blankest row near the boundary so text
lines are not severed) and the per-strip results are merged, with layout boxes
mapped back to source-image coordinates — no flags needed; FOCR_TIMING=1 logs
the strip plan. Second, a large input that still yields almost no text is
flagged: robot mode adds low_yield: true (plus yield_chars and
input_megapixels) to run_complete, human mode prints a stderr warning, and
--fail-on-low-yield turns it into exit 8 (low_yield) before any output is
written. A capture that is low-yield even after strip routing usually has
glyphs below ~12px — re-capture at higher resolution; no OCR engine recovers
7px text. Manual alternative for exotic layouts: cut the page yourself and run
focr ocr-batch strip1.png strip2.png ….
Tasks (--task). Convenience routing over the model zoo (focr models). --task ocr
(the default) is plain document OCR, unchanged. --task formula, tables, chart,
molecular, and geometry are served by GOT-OCR2's OCR with format: mode, so each
implies --format (an explicit --format composes idempotently) and needs the
got-ocr2 model: focr pull got-ocr2, then --model got-ocr2.int8.focrq. --task chart
and --task formula also pad the image to a white square first, because GOT misreads
both when upstream's square resize stretches them; --format alone keeps that resize,
and so does every other task. GOT can also read one region of an image, as upstream's
fine-grained mode does: --box x1,y1,x2,y2 in the image's pixels (or a point x,y), or
--color red|green|blue for a frame of that colour drawn around the text. Either composes
with --format; a box does not compose with --task chart or --task formula, because
they pad the image. --task music
has two valid lanes: TrOMR is the native OMR path and returns MusicXML, while GOT-OCR2
can still run its sheet-music format mode. Use focr pull tromr, then --model tromr.int8.focrq --task music
for a full printed/scanned page or a staff crop. Use focr pull tromr --quant f32
and --model tromr.focrq when you need the bit-exact reference artifact. You can also use the GOT lane
(--model got-ocr2.int8.focrq --task music). --task describe (photo description / VQA) is served by the smolvlm2
model: focr pull smolvlm2, then --model smolvlm2.int8.focrq --task describe, optionally with --question "What color is the car?". SmolVLM2 has no instruction modes; the task is the question
(default: the model-card caption prompt). --task chart-data is the OneChart path: it
runs chart-to-dict extraction with the number-head reliability check and needs a
onechart artifact, for example focr pull onechart, then --model onechart.int8.focrq.
A reading that does not pass that check says so with a chart_unverified warning. Pointing a
specialized task at the wrong model family fails with usage guidance before any weights
load.
Tuning flags: --base-size and --image-size (preprocessing resolution), --crop-mode (gundam or base), --max-length (decode token cap), --temperature (only 0: every model decodes greedily, and anything else exits 2 before a model loads), --no-repeat-ngram and --ngram-window (the sliding no-repeat n-gram decode guard).
OCR many images in one process, loading the model once and reusing it across all pages.
focr ocr-batch a.png b.png c.png --json # one load, many pages
FOCR_INT8_ATTN=1 FOCR_INT8_LMHEAD=1 \
focr ocr-batch *.png --experimental-full-int8 # explicitly arm the gated cache
FOCR_INT8_ATTN=1 FOCR_INT8_LMHEAD=1 FOCR_BATCH_SPINE=1 \
focr ocr-batch *.png --experimental-full-int8 --json
FOCR_BATCH_SPINE=0 focr ocr-batch *.png --json # force the sequential oracle pathWith --json, each image's row says how its decode ended: finish_reason, any
warnings, and chart on a OneChart run. An Unlimited-OCR-2 page stopped by its stage
budget or position limit, or a v1 page the runaway guard stopped, keeps its markdown,
but reads ok: false with an error, the same stop that makes focr ocr exit 5. So check ok, not whether markdown is present.
ocr-batch loads the model once either way. Unlimited-OCR defaults to the
conservative recipe path. Its continuous-batch R-SWA spine currently belongs to
the explicitly gated all-int8 experiment, so FOCR_BATCH_SPINE=1 uses that
spine only with --experimental-full-int8 and both accuracy switches shown
above. The dense zoo path batches GOT-OCR2, SmolVLM2, and OneChart decode streams. GOT-OCR2 and OneChart
reuse hydrated SAM weights, projectors, and widened embedding tables; SmolVLM2
does the same for its SigLIP tower, modality projection, and text embeddings.
The same statics are cached on the loaded model for ordinary sequential pages
too, so a multi-page PDF or repeated in-process calls no longer re-widen those
large tensors for each page.
FOCR_BATCH_SIZE defaults to 128 active streams and clamps at 256;
FOCR_BATCH_PACK=1 groups similar prefill lengths before restoring output
order. Without the experimental flag, attention and lm_head stay high
precision by construction.
To watch a long batch, add --progress-events PATH (- for stderr). Each line
is one JSON object: batch_start with the resolved thread budget, model and
backend, then image_complete or image_error as each image ends, with the
pages per hour measured so far and eta_ms, and batch_end with the outcome.
stdout does not change, so --json is still one final object. eta_ms is
null until one image has ended, then the mean time per image so far times the
images left; the first image carries the model load, so the estimate starts
high. With --multi-page the lines are page_complete and page_skipped, and
batch_start says the pages are one cross-page pass, not independent images.
focr robot schema lists every field under batch_progress. The flag refuses
FOCR_BATCH_SPINE, which decodes the images together and has no per-image end
to report.
--inputs-from FILE reads more paths, one per line, after any named on the
command line (- reads stdin). --output-dir DIR writes each image's markdown
to DIR/<stem>.md as it ends, so a stopped batch keeps what it finished; two
inputs that would write one file are refused before any work.
An image that fails does not stop the batch: the run goes on, and fails with the
first failure's exit code only if no image was read. --fail-fast stops at the
first failure instead. Ctrl+C stops at the image it interrupted, and the run
exits 6. Either way the images that ended are still reported, and --json adds
"stopped": "image_failed" or "stopped": "cancelled".
Download a manifest-compatible model and tokenizer into the cache, verifying
every byte. The embedded v0.7.0 Unlimited-OCR entry declares the
runtime-compatible conservative recipe
unlimited-ocr-ffn-int8-attn-bf16-lmhead-bf16-v1; the historical schema-v1
full-int8 entry remains incompatible and is rejected.
focr pull # versioned conservative Unlimited-OCR artifact
focr pull unlimited-ocr-2 # long-document successor (4.17 GB, three parts)
focr pull got-ocr2 # structured OCR model
focr pull smolvlm2 # image description / VQA model
focr pull onechart # chart-to-data model
focr pull tromr # sheet-music OMR model (int8 default)
focr pull tromr --quant f32 # bit-exact reference artifact
focr pull got-ocr2 --quant int8 --json # explicit quant, machine-readable
focr pull --manifest ./manifest.json # compatible custom default manifestDownloads run over asupersync's native HTTP stack (rustls + webpki-roots), reassemble GitHub split parts, verify against a committed SHA256 manifest, and cache to ~/.cache/franken_ocr/models. Manifest schema v2 requires an exact recipe for every quant; size, paths, counts, declared sizes, HTTPS URLs, and hashes are validated before installation. The release-bound schema-v2 manifest is embedded in each binary; a local or HTTPS override is explicit.
The v0.7.0 primary Unlimited-OCR artifact uses the conservative exact recipe and installs as unlimited-ocr/unlimited-ocr.v0.7.0.int8.focrq. The embedded manifest pins its three release parts, byte count, and final SHA256; the historical full-int8 artifact remains only in the schema-v1 manifest used by already-released v0.6 binaries.
Every model installs as one package under ~/.cache/franken_ocr/models/<model-id>/.
Tokenizer sidecars cannot collide, and a pull replaces the whole directory at once, so
a crash never leaves a new artifact beside an old tokenizer. The resolver searches
those packages, then the cache root,
so --model onechart.int8.focrq, --model tromr.int8.focrq, and
--model tromr.focrq work after their pulls. TrOMR publishes int8 and f32;
the default focr pull tromr fetches the int8 artifact, while
focr pull tromr --quant f32 fetches the bit-exact f32 reference artifact.
List the model zoo with each id, runtime status, task set, model families, default artifact name, and compatible or blocked pull recipes.
focr models # human table
focr models --json # machine-readable listWhich model do I use?
| Model | Status | Use it for | Notes |
|---|---|---|---|
unlimited-ocr (default) |
runtime ready, pull ready | Plain-text document OCR for general documents and PDFs. This is what focr ocr runs by default. |
focr pull installs the v0.7.0 conservative exact-recipe artifact; raw BF16 and locally converted compatible artifacts are also supported. |
got-ocr2 |
ready | Specialized structured output the default cannot produce: formulas, tables, charts, molecular diagrams, geometry, and sheet music. | Heavier per page; `--task formula |
smolvlm2 |
ready | Photo description and VQA through --task describe [--question "..."]. |
focr pull smolvlm2 installs smolvlm2.int8.focrq plus tokenizer.json in the model subdirectory. |
onechart |
ready | Chart-to-data extraction through --task chart-data. |
focr pull onechart installs onechart.int8.focrq, vocab.json, merges.txt, and added_tokens.json. The native path runs the fixed chart prompt, SAM/projector splice, OPT KV-cache decode, num_decoder, JSON repair, and reliability distance check. Its number head is the part to trust; its text often is not, and an unverified reading warns. |
tromr |
ready | Polyphonic sheet-music OMR through --task music. |
focr pull tromr installs tromr.int8.focrq plus the rhythm, pitch, lift, and note tokenizer tables; focr pull tromr --quant f32 installs the bit-exact tromr.focrq reference artifact. Staff crops and full pages both run; bad staves are skipped with reasons when at least one staff recognizes, and over-budget systems can split at detected barlines. |
unlimited-ocr-2 |
ready | Baidu's long-document successor to the default model (sparse routed attention across pages). | focr pull unlimited-ocr-2 installs the certified int8 artifact (4.17 GB) and its own tokenizer into models/unlimited-ocr-2/. --model unlimited-ocr-2 then reads single pages and documents of any length (--multi-page, read in windows of 10 pages); --model <dir> also runs a raw checkpoint. A document that stops early at its position limit or forward budget writes its pages, then exits 5. unlimited-ocr stays the default until v2 passes its default gates. |
trocr, pix2tex |
planned | Handwriting and LaTeX OCR lanes. | Registered descriptors only until their forward paths ship. |
unlimited-ocr is the fast default for ordinary text. Reach for got-ocr2 only when you need format extraction (formulas, tables, charts, etc.); it is a much larger decode and is not meant to replace the default for plain text. Install and run it with:
focr pull got-ocr2 # download the weights + tokenizer
focr ocr --model got-ocr2.int8.focrq page.png # plain-text OCR
focr ocr --model got-ocr2.int8.focrq --format eq.png # structured .mmd: LaTeX / tables / charts / music
focr ocr --model got-ocr2.int8.focrq --task tables page.png # task shorthand (implies --format)How far to trust the structured lanes. These are small synthetic sets, measured on the published artifacts. They can show a lane failing; they do not show one working on your documents. None of these lanes warns on a wrong reading except OneChart.
| Lane | Measured | Advice |
|---|---|---|
--task tables |
One table, read exactly. | |
--task molecular |
One molecule, read correctly. | |
--task chart |
29 of 36 bar charts have every value right. The misses are plausible wrong numbers. | Check the numbers against the chart. |
--task formula |
3 of 8 formulas right. The rest come back as SMILES or TikZ, not as bad LaTeX. | Expect misses, and check each formula. |
--task music on GOT-OCR2 |
One two-bar staff, misread. | Use TrOMR. |
--task chart-data |
Text gave usable values on 0 of 36 charts. The number head averaged within 10% of the range on 31 of 36. | Read chart.pred_locs from --json: bar heights from 0 to 1, in order. It does not say how many bars there are. |
Tables, the molecule, music and formulas read the same on the upstream f32 checkpoint.
Charts do not, in both directions: at --task chart, int8 misses two charts that f32
reads right and reads three that f32 misses, so f32 would not fix this lane. Evidence:
artifacts/accuracy/bd-kd75/ and
tests/fixtures/got/format_corpus/.
Run SmolVLM2 (photo description / VQA):
focr pull smolvlm2
focr ocr --model smolvlm2.int8.focrq --task describe photo.jpg
focr ocr --model smolvlm2.int8.focrq --task describe --question "How many dogs are there?" photo.jpgRun OneChart (chart-to-data extraction):
focr pull onechart
focr ocr --model onechart.int8.focrq --task chart-data chart.pngRun TrOMR sheet-music OMR:
focr pull tromr
focr ocr --model tromr.int8.focrq --task music score-page.png -o score.musicxml
focr pull tromr --quant f32
focr ocr --model tromr.focrq --task music score-page.png -o score.musicxml
focr convert /path/to/tromr/model.safetensors -o tromr.int8.focrq --quant int8 --model-id tromr
scripts/tromr_convert_e2e.sh
scripts/tromr_music_e2e.sh
scripts/realscan_music_gate.shThe TrOMR runtime accepts a single staff crop or a full printed/scanned page. If the detector finds multiple staves, it deskews the page globally, crops staves top-to-bottom, recognizes each staff through the same certified single-staff path, and emits one MusicXML part per staff; if it finds fewer than two staves, it treats the whole image as the staff input. For genuinely over-wide systems, the page path uses the five detected staff-line anchors to find thin barline columns, splits at the farthest usable barline within the positional budget, recognizes each segment sequentially, and concatenates the semantic stream while suppressing continuation clef/key/time artifacts. A multi-staff page succeeds when at least one staff recognizes, logging skipped staves with bbox and reason; an all-fail page errors with every staff reason named. The published int8 artifact is 61 MB and quantizes the 40 decoder-GEMM candidate tensors; the 86 MB f32 artifact stays published for bit-exact reference work. The int8 default is accepted with a ledgered discrepancy on one degraded Spohr page where both int8 and f32 garble differently while the corpus gate verdict stays unchanged. Local conversion is still available when you have your own TrOMR checkpoint.
The real-scan music corpus lives in tests/fixtures/realscan_music/. It starts with public-domain Spohr page and staff fixtures, tier-1 attributes that can be verified by eye, and one frozen MusicXML regression anchor. scripts/realscan_music_gate.sh is model-gated and exits successfully when local TrOMR weights are absent; when weights are present it checks attributes, frozen anchors, and page-level staff event floors. This is the real-scan regression base for the TrOMR lane, not a claim that broad note-level SER coverage is complete.
Offline weight transformation: a bf16 safetensors checkpoint into a custom .focrq artifact. Decoder tensors are int8 where that policy is validated for the model; tiny models such as TrOMR can stay f32 by default while still using the same one-binary runtime.
focr convert model.safetensors -o unlimited-ocr.focrq --quant int8
focr convert unlimited-ocr-2/ -o unlimited-ocr-2.v0.1.0.int8.focrq --quant int8
focr convert got.safetensors -o got-ocr2.int8.focrq --quant int8 --model-id got-ocr2
focr convert smolvlm2.safetensors -o smolvlm2.int8.focrq --quant int8 --model-id smolvlm2
focr convert onechart.safetensors -o onechart.int8.focrq --quant int8 --model-id onechart
focr convert tromr/model.safetensors -o tromr.int8.focrq --quant int8 --model-id tromr
focr convert model.safetensors -o out.focrq --quant int8 --jsonFor Unlimited-OCR, conversion stamps recipe unlimited-ocr-ffn-int8-attn-bf16-lmhead-bf16-v1, quantizes exactly 2,148 FFN/expert matrices, and copies all 48 attention projections plus lm_head at source precision. The source SHA256 is stamped into the header, and the loader rejects any default-model .focrq whose tensor dtypes violate that recipe.
Unlimited-OCR-2 converts from its checkpoint directory (the index plus two shards). The same 2,148 matrices are int8 under recipe unlimited-ocr-2-ffn-int8-attn-bf16-lmhead-bf16-v1. Attention, lm_head, and every SR-SWA dash_router and indexer tensor stay at source precision; the router steers a discrete block choice, so it is never quantized. The header's source_sha256 is the SHA-256 over the two shard digests in index order, and each shard is listed in its provenance. The loader refuses a v2 .focrq with any other recipe id, any other source, or a tensor stored outside the recipe. v2 has no int4 recipe yet.
--model-id selects the architecture descriptor, tied-head policy, tensor-name prefixes, tokenizer expectation, and license notice. Without it, the converter picks the Unlimited-OCR generation whose tensor census the source matches; the zoo models need it. An id that disagrees with the source's census exits 2 and names both, after reading only the shard headers. --arch <target> records architecture-specific prepacking intent (default: generic). Int4 remains gated and unvalidated.
Agent-facing surface: versioned NDJSON, self-describing, line-oriented, easy to pipe.
focr robot run page.png # stream OCR events as NDJSON (same flags as ocr)
focr robot schema # self-describing, versioned event/contract schema
focr robot health # model present? arch features? thread budget?
focr robot backends # detected SIMD tiers + core count
focr robot selftest # int8 kernel vs scalar oracle on this host
focr robot triage # quick_ref + health + recommendations + commandsfocr robot selftest runs the selected dense-int8 implementation against the bit-identical scalar oracle across a shape battery, including the worst-case K=6848 i32-accumulation overflow case, and emits one JSON verdict; it exits 1 on either numeric divergence or a route-trace mismatch. The payload separates hardware_selected from the effective selected route and lists the branch-derived executed_routes. oracle_independent=false is explicit for scalar/autovec because those paths invoke the oracle implementation itself. Set FOCR_FORCE_ARCH to verify each available intrinsic tier independently.
focr robot triage is the first command an agent should run in an unfamiliar
checkout or host. It returns one JSON object with a compact command reference,
the live health payload, state-aware next commands, command templates, and the
exit-code dictionary.
For TrOMR music runs, robot mode adds a staff event before run_complete for
each detected staff. The event carries the 1-based staff index, total detected
staff count, page-space bbox, recognized or skipped status, and optional
reason. Music runs can also emit music_warning events for annotate-only
musical sanity observations: overfull bars, underfull non-final bars,
impossible note durations, and cross-staff key mismatches. Existing consumers
can ignore these additive events; strict consumers should refresh their schema
with focr robot schema.
focr ocr records each run in a local fsqlite store on a best-effort basis. A
store failure prints a note to stderr and never fails the OCR run itself. The
default store is ~/.cache/franken_ocr/runs.db; set FOCR_RUN_STORE to use a
different path.
focr runs --limit 10 # recent runs, plain table
focr runs --limit 10 --format json # one JSON object with a runs array
focr runs --format ndjson # one run record per line
focr runs --id <run-id> --json # inspect one run
focr sync export-jsonl --json # export the canonical audit log
focr sync export-jsonl --file runs.jsonl # choose the export path
focr sync import-jsonl --file runs.jsonl --jsonExports are canonical and atomic: the writer takes an exclusive lock, writes a
temporary file beside the target, fsyncs it, then renames it into place. Imports
are idempotent because records replace by run_id.
doctor is the local self-check and reversible repair surface. Detect-only mode
is read-only and exits 0 when healthy or 1 when findings are present. --fix
applies only safe repairs through one mutation chokepoint: every touched file is
backed up first under .doctor/runs/<run-id>/backups/, hashes and modes are
logged to actions.jsonl, and doctor undo <run-id> restores from that log.
Irreversible work, such as regenerating model artifacts, is refused with the
exact command to run manually. That includes a model whose tokenizer.json is
missing or is not the file that model pins, such as v1's beside a v2 artifact,
and an installed model that focr ocr --model <id> would not load, such as a
package still holding the previous release after an upgrade: for a published
model, doctor names the focr pull <model> that re-installs it.
focr doctor # human-readable detect-only report
focr doctor --json # one JSON object with typed findings
focr doctor --dry-run # planned blast radius, no mutation
focr doctor --fix # safe reversible repairs only
focr doctor undo <run-id> # restore a prior --fix run
focr doctor capabilities # detector/fixer/exit-code contract
focr doctor robot-docs # paste-ready agent handbookThe hot path is not a generic tensor interpreter. Each model is converted into a .focrq artifact, then executed through fixed-shape Rust code that calls model-specific kernels and keeps allocations out of the decode loop.
The backend keeps handwritten SIMD narrow. Ordinary Rust loops stay in place
where LLVM autovectorizes well; audited SIMD is reserved for int8 matmul kernels
whose scalar oracle is bit-identical and whose speedup is measured. That is why
robot backends reports both hardware ISA selection and the effective ordinary
dense-int8 route. It does not overclaim the separately dispatched packed-int4 or
offline-packed SMMLA paths; AMX remains absent until a real kernel lands.
Model artifacts load through a byte-range directory over one backing blob. The
safe default is an owned Vec<u8>, so a concurrent writer cannot truncate a
mapping and fault the process. Deployments that keep artifacts on immutable
inodes, such as read-only image layers, can set FOCR_MMAP=1 to opt into lazy
page-in and OS page-cache reuse. The parser and tensor accessors are identical.
The current optimization stack is deliberately specific:
| Surface | Optimization |
|---|---|
| Decoder GEMMs | Offline .focrq conversion packs recipe-selected decoder weights for int8 matmul while keeping accuracy-sensitive tensors high precision. Artifact-level accuracy remains a release gate. |
| Weight loading | Owned bytes are the safe default for .focrq and safetensors artifacts. FOCR_MMAP=1 explicitly opts trusted immutable artifact inodes into lazy page-in and OS page-cache reuse. |
| Per-token decode | R-SWA generated-token ring KV and a cached decoder forward. The fused QKV int8 projection remains an explicitly gated experiment until its independent accuracy gates pass. |
| Vision work | SAM, CLIP, and SigLIP linears are pre-transposed at hydration, then cached on the model. GOT-OCR2, SmolVLM2, and OneChart cache their vision towers, projectors, and widened embed tables once per loaded model. SAM attention windows run independently across Rayon; relative-position work is hoisted and walked in cache-friendly rows. |
| Batch throughput | FOCR_BATCH_SPINE=1 advances active streams through shared decode steps while preserving each stream's KV cache, position, output cap, and byte identity. |
| TrOMR | Staff detection, deskew, ink-extent trim, neighbor-bounded band growth, barline segmentation for over-budget systems, ResNetV2/ViT glue, and MusicXML emission are native Rust. |
Apple Silicon / ARM64. The aarch64 backend detects NEON dot-product (SDOT) and matrix-multiply int8 (SMMLA / i8mm) at runtime. Ordinary dense decoder linears currently use the LLVM-autovectorized scalar loop by default on macOS: interleaved real-decode measurements beat forced SDOT, while forced SMMLA is slower still. FOCR_INT8_AUTOVEC=0 restores the natural SDOT choice for a bounded comparison, and FOCR_FORCE_ARCH=sdot|smmla|scalar focr robot selftest forces and verifies each available branch. Packed int4 and offline-packed SMMLA have separate dispatch and are not labeled by the ordinary-dense route. On non-Apple ARM64, the effective route can favor SMMLA. Norms, softmax, preprocessing, and TrOMR's f32 glue remain simple loops for LLVM. The vision path reduces repeat work by hydrating SAM, CLIP, and SigLIP weights once, storing GEMM-ready pre-transposed linears, exposing independent SAM attention windows to Rayon, and walking relative-position rows in cache-friendly order.
Intel / AMD x86-64. The x86 backend detects AVX-512-VNNI, AVX-VNNI, and AVX2 in that order, then falls back to scalar. AVX-VNNI and AVX-512-VNNI take the native dot-product path for int8 decode; AVX2 uses an exact non-saturating implementation rather than a shortcut that could corrupt accumulation. AMX is not advertised until there is a real AMX backend. Forced-tier selection reaches the named implementation, and robot selftest records that executed route rather than trusting capability metadata. The same binary therefore runs correctly on older AVX2-only Zen/Intel hosts and selects wider VNNI kernels on newer CPUs. The model-level SAM/CLIP/SigLIP hydration cache and the pre-transposed linear layout also help x86 hosts by removing repeated full-weight transposes before the BLAS-like matmul calls. The non-kernel glue is kept in plain, predictable loops so LLVM can vectorize it for the host CPU instead of forcing a brittle hand-written SIMD path.
Quantization policy. The conservative candidate set is exact: the dense layer-0 MLP and the routed/shared MoE expert FFN matrices. Attention q/k/v/o and lm_head are not part of that set; they stay high precision unless both independent experimental gates are explicitly armed. The vision tower, projector, embeddings, MoE router, and all norms also stay high precision. This storage policy does not itself certify an artifact; the v0.7.0 artifact separately passes its hard-page and corpus gates.
Experimental fused QKV decode. The all-int8 decoder stacks the q/k/v projection
weights into one [3*qkv_dim, hidden] panel and runs one quantize-plus-GEMV pass
per token instead of three separate projection calls. It is reachable only when
FOCR_DECODE_INT8=1, FOCR_INT8_ATTN=1, and FOCR_INT8_LMHEAD=1 are all truthy.
Set FOCR_QKV_FUSED=0 to restore the older three-call path for comparison.
TrOMR-specific CPU primitives. The sheet-music lane has native staff preprocessing, global deskew and staff grouping, ink-extent crop trimming, neighbor-bounded band growth for wide systems, barline-column detection for over-budget bands, TF-SAME padding arithmetic, TF-SAME max-pool support, a Torch-parity GroupNorm kernel with optional fused ReLU, and a hybrid ResNetV2 plus ViT encoder checked at cosine 1.0 against oracle seams. Weight-standardized convolutions are folded during checkpoint export so the runtime can keep the conv path simple. The decoder includes self-attention, cross-attention, GEGLU, stream embeddings, and four output heads, then merges the rhythm/pitch/lift streams into semantic music tokens and partwise MusicXML. Opaque-alpha RGBA staff images take the RGB luma path rather than upstream's blanket inverted-alpha path, because the literal upstream rule blanks fully opaque demo staves; docs/DISCREPANCIES.md records the measured SER impact. The TrOMR closeout pins mean SER at 0.211 on committed single-staff examples and shows detection-lossless full-page reads at 0.125 / 0.040 SER for stacked staves. These pieces are scalar Rust loops designed for LLVM autovectorization across Apple Silicon and Intel/AMD CPUs; hand-written wide SIMD stays limited to int8 matmul kernels where the proof and measurement support it.
Zoo performance evidence. The latest zoo gauntlet keeps paired reference rows for GOT-OCR2, SmolVLM2, and OneChart. On an aarch64 host with NEON dotprod at eight threads, the native decode-per-token path measured 3.37x over Hugging Face CPU for GOT-OCR2, 2.58x for OneChart, and 1.67x for SmolVLM2. The ledger also records the full end-to-end rows, including the current artifact-load tax, so the project can improve throughput without hiding unfavorable totals.
Instrumentation and batch-spine bring-up. FOCR_TIMING=1 prints nested timing rows for the native forward, including SAM hydrate, SAM forward, per-block attention, and per-block MLP stages. That makes the current bottleneck visible: large pages can spend their wall time in vision attention rather than model artifact loading. The vision hydration path now builds SAM, CLIP, and SigLIP weight bundles once per loaded model, including GEMM-ready pre-transposed linears, so later pages skip repeated transpose work. GOT-OCR2, SmolVLM2, and OneChart apply the same model-cache pattern to their vision towers, projectors, and widened embed tables. The SAM attention pass keeps the math bit-identical while reducing overhead: independent windows run across Rayon, relative-position tables are hoisted once per block, Q/K/V head splits copy contiguous slices, and the bias add walks (ky, kx) rows directly. The dense decoder batch spine also has a byte-identity-gated helper for Qwen/Llama and OPT-family decode steps. Prefill stays per stream; active non-EOS streams then advance through one batch step while each stream keeps its own KV cache, absolute position, and per-stream emission cap. The public ocr-batch path keeps FOCR_BATCH_SPINE as an opt-in switch while new batch plumbing earns correctness and perf evidence.
Correctness gates. Every accelerated int8 GEMM has a bit-identical scalar fallback. focr robot selftest includes the doctrine worst case, K=6848, plus model-specific overflow rows for the ready int8 decoder families. It verifies parity and that every call executed the selected route; forced subprocess coverage sweeps every host-available ISA tier. The batch scheduler and decode cache are guarded by byte-identity tests against the proven sequential path.
There is no GPU backend: inference is CPU-only by design (see Limitations), and a 3B-parameter VLM on CPU is minutes-per-page territory on ordinary hardware, not seconds. Within that envelope, these are the levers that actually move wall time, roughly in order of impact:
- Rule out swapping first. The default Unlimited-OCR artifact is ~4 GB on disk and inference peaks well above that; on an 8 GB machine the slowness is usually paging, not compute. Either add RAM headroom, close other large processes, or use a smaller model (below).
- Match the model to the task. For plain text/structured pages,
got-ocr2.int8.focrq(~0.8 GB) loads and runs far lighter than the 4 GB Unlimited-OCR default;onechart(~0.3 GB) andsmolvlm2(~1 GB) are likewise much smaller.focr modelslists the zoo;focr pull <model>installs it. - Amortize the model load. Eligible single-image
focr ocrruns are served by the resident warm-model daemon by default: the first run spawns a per-model background process that keeps the loaded weights in RAM, so back-to-back invocations skip the multi-GB artifact load (measured about 2 s saved on a 14 s page with the artifact in the OS page cache); it auto-exits after 10 idle minutes (FOCR_RESIDENT_IDLE_SECS; opt out with--no-resident/FOCR_NO_RESIDENT=1). For a known batch of images,focr ocr-batch a.png b.png ...(weights load once, results stream per page) or the library'srecognize_batchremains the throughput path, andFOCR_BATCH_SPINE=1additionally decodes dense-zoo pages through shared batch steps. - Check the thread budget. The kernel pool defaults to physical cores, and on an Apple-silicon Mac to its fastest core tier only (
--threads NorFOCR_THREADSoverrides it). If the host is shared or cgroup-limited, set it explicitly; oversubscription with hyperthreads or other tenants slows the int8 GEMMs down. - Verify the SIMD tier.
focr robot backendsshows the detected ISA and the effective dense-int8 route. On x86 you want AVX-512-VNNI > AVX-VNNI > AVX2; plain scalar means an old CPU (or a mis-forcedFOCR_FORCE_ARCH) and will be several times slower. - Cut the work.
--pages 3,5-9OCRs only the PDF pages you need;FOCR_MAX_NEW_TOKENS(or--max-length) caps runaway generations;FOCR_MMAP=1on immutable artifact inodes gives lazy page-in and OS page-cache reuse across repeated runs. - Measure before tuning further.
FOCR_TIMING=1prints the nested stage breakdown (artifact load, vision attention, decode, output) so you can see whether your pages are load-bound, vision-bound, or decode-bound.
The conformance harness is built to leave reviewable artifacts rather than only a green test line.
| Artifact | Command or location | What it proves |
|---|---|---|
| Parity scorecard | scripts/ladder_scorecard.sh --out scorecard.json |
Runs L0-L5 in order, folds each rung's NDJSON into focr-ladder-scorecard/v1, and writes the raw stream beside the summary. |
| Skip-honest mode | scripts/ladder_scorecard.sh --out scorecard.json without weights |
Produces all_green:false and skipped_no_model:true, so a missing-model run cannot masquerade as a certified release. |
| FeatureUniverse / SurfaceMatrix | docs/FEATURE_PARITY.md, tests/surface_matrix.rs |
Accounts modeling features, ops, CLI surfaces, robot events, parity gates, and alien-artifact families as present, partial, missing, n/a, or excluded; partial never rounds up. |
| Three-pillar gauntlet cert | python3 scripts/gauntlet_cert.py --from-parity docs/FEATURE_PARITY.md --scorecard-out /tmp/focr-release-scorecard.json |
Scores the surface pillar from the live parity ledger and emits franken_ocr.gauntlet.scorecard.v1; performance and conformance gates stay separate, so one green pillar cannot hide another regression. |
| Release certification | --bundle, then --finalize-bundle with downloaded workflow manifests and three trusted signer inputs, then --release-readiness |
The provisional bundle is always uncertified. The production finalizer live-replays one exact-HEAD run of CI, dist, Model Parity, and Performance Gauntlet, derives every strict field, verifies three registry-pinned OpenPGP signatures, proves the candidate in memory, and only then persists certified:true. |
| Benchmark guardrail | python3 scripts/bench_guardrail.py --stages artifacts/.../focr_stages.json --baseline benches/.bench-history/baseline.json --parity-receipt tests/fixtures/ladder_scorecard/scorecard_armed.json |
Compares fresh stage timings against committed per-regime baselines, refuses performance reporting without an all-green parity receipt, marks noisy or posture-mismatched rows ineligible, and exits successfully when model fixtures are absent. |
| Real-scan music corpus | scripts/realscan_music_gate.sh, tests/fixtures/realscan_music/ |
Runs TrOMR over public-domain Spohr staff/page fixtures, checks human-verifiable attributes and frozen MusicXML anchors, and uses robot staff events for page-level floors. |
| TrOMR page resilience | cargo test --locked --lib native_engine::tromr::tests::tromr_page |
Checks stacked-staff order, measured single-staff SER floors, one fittable-plus-one-unfittable staff page, and all-fail pages whose error names every skipped staff. |
| Property invariants | cargo test --locked --test property_suite |
Runs bounded proptest cases for SIMD-vs-scalar int8 GEMM identity, K=6848 i32 accumulation, preprocess geometry, .focrq parser totality under byte mutation, and tokenizer round-trip when a tokenizer artifact is present. |
| Fuzz seed corpus | fuzz/corpus/, cargo fuzz run focrq_parse|safetensors_parse|image_decode|pretok_split |
Seeds four untrusted-input fuzz targets covering .focrq parsing, safetensors parsing, image ingest, and pretokenizer splitting. The latest post-head-to-head sweep ran 3.65M cases with zero crashes, and the repo keeps the resulting corpus growth under fuzz/corpus/. |
| Conformal ratchet | docs/conformance/RATCHET.md, src/conformance.rs |
Computes per-category lower bounds from Jeffreys posterior and Hoeffding instruments, then rejects any category that drops below its committed floor. |
| Ville e-process monitors | python3 scripts/gauntlet_cert.py --eprocess-fold test-log.ndjson --eprocess-state /tmp/focr-eprocess-state.json |
Folds live invariant observations for KV capacity, K=6848 i32 no-overflow, same-input determinism, and SIMD-vs-scalar bit identity into persistent anytime-valid monitors. |
| Convergence gate | python3 scripts/gauntlet_cert.py --convergence docs/gauntlet/ROUNDS.jsonl |
Requires at least 10 gauntlet rounds and a clean tail before declaring the investigation converged. |
| Capacity certificate | cargo test --locked --test many_pages_without_deadlock capacity_certificate_bounded_stream_soak -- --nocapture |
Exercises the bounded stream_pages channel, records queueing percentiles, proves the channel bound, and checks that the kernel pool width stays stable. |
| Fixture provenance | tests/fixtures/MANIFEST.toml, tests/fixtures/PROVENANCE.md |
Records how committed fixtures were generated, including armed and unarmed scorecard examples. |
For an armed release receipt, provide the real model and fixture roots:
FOCR_FIXTURES_DIR=/path/to/fixtures/native_f32 \
FOCR_MODEL_PATH=/path/to/model-00001-of-000001.safetensors \
scripts/ladder_scorecard.sh --out scorecard.jsonThe scorecard is the compact receipt. The adjacent scorecard.raw.ndjson file is the audit trail.
The broader gauntlet has its own self-test and scorecard path:
python3 scripts/gauntlet_cert.py --self-test
python3 scripts/gauntlet_cert.py --from-parity docs/FEATURE_PARITY.md \
--scorecard-out /tmp/focr-release-scorecard.json
python3 scripts/gauntlet_cert.py --bundle .gauntlet-output/bundle
# Finalize only with the workflow manifests and signer identities described in
# docs/gauntlet/RELEASE_CERTIFICATION_TEMPLATE.md.
python3 scripts/gauntlet_cert.py --release-readiness \
--readiness-out .gauntlet-output/release_readiness.jsonThe committed gauntlet bundle stays conservative: its surface lower bound is not inflated beyond the evidence in docs/FEATURE_PARITY.md, and its release certificate remains certified:false unless the strict finalizer verifies fresh workflow evidence, production audit receipts, and three registry-pinned OpenPGP signers. v0.7.0 publishes locally and remotely hash-verified release bytes without claiming that unavailable governance certificate.
| Variable | Effect |
|---|---|
FOCR_MODEL_PATH |
Override the model artifact path (a .focrq blob or a safetensors directory). For the current default, point this at raw BF16 weights or an artifact using exact recipe unlimited-ocr-ffn-int8-attn-bf16-lmhead-bf16-v1; the historical schema-v1 full-int8 pull is rejected. |
FOCR_MODEL_DIR |
Add one or more model search roots before the default cache. A bare focr ocr can resolve pulled artifacts from this directory without --model. |
FOCR_QUANT |
Pick the quant-suffixed artifact name during cache resolution when multiple variants are present. |
FOCR_MANIFEST_URL |
Override the release-bound embedded manifest with a local path or an HTTPS URL. |
FOCR_RUN_STORE |
Override the local run-history database path. Defaults to ~/.cache/franken_ocr/runs.db. |
FOCR_MMAP |
Opt into read-only mmap for trusted artifact inodes that are guaranteed immutable for the process lifetime. Unset is the safe owned-buffer default. On a 20-page unlimited-ocr-2 document, output was byte-identical and peak footprint fell from 11.13 GB to 6.64 GB. Peak RSS barely moved (10.76 GB), because mapped pages count towards it until the system needs them back, and wall time doubled in that one run on a busy host, so measure before relying on it. |
FOCR_MEMORY_BUDGET |
How much memory --page-window auto may plan for, as bytes or a whole number of KiB, MiB, GiB or TiB. Defaults to three quarters of physical memory. |
FOCR_NO_REPEAT_NGRAM |
Override the sliding no-repeat n-gram size for decode (default 35). |
FOCR_GOT_NO_REPEAT_NGRAM |
Override the GOT-OCR2 global no-repeat n-gram size (default 20, matching the upstream model; 0 disables the repetition guard). |
FOCR_GOT_FORMAT |
Force GOT-OCR2's OCR with format: structured-output mode, the env analog of --format and the format-implying --task values. |
FOCR_SMOLVLM2_QUESTION |
The smolvlm2 describe/VQA question (the env analog of --question; the CLI flag outranks it; default: the model-card caption prompt). |
FOCR_TROMR_SAMPLE |
Enable TrOMR's upstream top-k/T=0.2 sampling arithmetic from a deterministic PCG32 seed. Unset uses the default per-head argmax path. |
FOCR_TROMR_SEED |
Seed for FOCR_TROMR_SAMPLE; defaults to 0. Same seed means the same TrOMR decode stream on every supported CPU. |
FOCR_TROMR_SPLIT |
1 arms the experimental barline-split rescue for staff bands too wide for the 1280-column position budget. Off by default: split segments lose absolute pitch registration (measured), so the default is an honest per-staff skip. |
FOCR_MAX_NEW_TOKENS |
Cap the number of generated tokens (the engine's max_length; default 32768). An explicit --max-length flag outranks it. Capping never changes the per-step math, so a capped run's tokens are a true prefix of the full run's. |
FOCR_DECODE_INT8 |
Request the experimental all-int8 Unlimited-OCR decoder. Truthy values require both FOCR_INT8_ATTN=1 and FOCR_INT8_LMHEAD=1; otherwise the command fails with a usage error. The default is the conservative recipe path. |
FOCR_INT8_ATTN |
Independent accuracy gate for int8 attention q/k/v/o weights. Default off. It does not select the all-int8 decoder by itself. |
FOCR_INT8_LMHEAD |
Independent accuracy gate for int8 lm_head. Default off. It does not select the all-int8 decoder by itself. |
FOCR_DECODE_STATELESS |
Force the stateless re-prefill decoder, kept as a parity oracle for the cached decode path. |
FOCR_DECODE_F32 |
Unlimited-OCR (v1 and v2): decode on an all-f32 cache (FFN/expert weights widened to f32 instead of int8), the cached path that reproduces the f32 reference's ids. Needs the raw checkpoint, not a quantized artifact, and excludes FOCR_DECODE_STATELESS and FOCR_DECODE_INT8. Slower than the default and far faster than stateless. |
FOCR_QKV_FUSED |
Controls fused q/k/v projection inside the experimental all-int8 decoder. Default is on within that experiment; set 0, off, false, or no for its older three-call comparison path. |
FOCR_BATCH_SPINE |
Arm continuous batching. For Unlimited-OCR, the current R-SWA spine requires the explicitly gated all-int8 decoder; without it, pages use the conservative sequential path. The dense zoo spine covers GOT-OCR2, SmolVLM2, and OneChart. Set 1, on, or true to arm it. |
FOCR_BATCH_SIZE |
Maximum in-flight stream count for the continuous-batch spine. Defaults to 128 when the spine is armed; blank, invalid, or 0 also use that default, and larger values are capped at 256. |
FOCR_BATCH_PACK |
When present, admit pending streams by similar prefill length inside the batch scheduler. Output order is restored before return, and each stream's tokens stay independent; unset preserves submission-order admission. |
FOCR_BATCH_VISION |
Inside the batch spine, run the vision tower batched across pages (the default). 0/off/false/no reverts to the per-page vision loop. Read only when the spine is armed. |
FOCR_UNLIMITED_VISION_CACHE |
Cache Unlimited-OCR's immutable SAM weights and pretransposed bridge projector on the loaded model (default). 0/off/false/no restores per-page hydration for diagnostics and memory comparisons. |
FOCR_THREADS |
Override the process-wide kernel thread budget. Default is the PHYSICAL core count (hyperthreads oversubscribe the int8 GEMMs), and on a Mac with two core tiers only the fastest tier (hw.perflevel0.physicalcpu): the slower tier sets the pace of every fork-join section (on a shared M5 Ultra, 12 Super + 24 Performance cores as macOS names them, all 36 took 2.4-2.6x the wall of 12 and about 6x the CPU). On iOS one core is left to the UI. Read once at startup; every pool-sizing consumer uses it. --threads N on ocr and ocr-batch outranks it for one run, and focr ocr then loads its own model, because a resident daemon keeps the budget it started with. |
FOCR_TIMING |
Emit nested native-forward timing rows for performance work, including SAM hydrate/forward/block/attention/MLP splits and decode/output stages. Interactive progress is disabled while this line-oriented trace is active. --timing on ocr and ocr-batch does the same for one run; either way focr ocr loads its own model, so the rows reach your stderr. |
FOCR_NO_PROGRESS |
Disable the interactive stderr progress bar shown during multi-page PDF and sequential ocr-batch runs (any value other than empty or 0). The bar already auto-disables when stderr is not a TTY and in --robot/--json modes; this is the explicit opt-out for TTY sessions. |
FOCR_FORCE_ARCH |
Force an available SIMD tier (sdot/smmla/scalar/avx2/avxvnni/avx512vnni) for CPU dispatch; used by robot selftest, robot backends, and pinned perf runs. |
FOCR_INT8_AUTOVEC |
Apple-only ordinary dense-int8 route switch. Default uses measured-faster LLVM autovec; 0/off/false/no restores SDOT when no valid FOCR_FORCE_ARCH override is active. It does not affect packed-int4 or offline-packed SMMLA paths. |
FOCR_RESAMPLE |
Preprocess resampling kernel. Unset (default): the image crate's CatmullRom. pil-bicubic: a Pillow-bit-exact fixed-point BICUBIC at every resize site, for reference-exact comparison against the PIL/torch oracle (DISC-001 in docs/DISCREPANCIES.md). |
FOCR_STAGE_BUDGET_FORWARD_MS |
Override the forward stage budget in milliseconds (default 600000, i.e. 10 minutes). 0 (or unlimited) disables the stage timeout entirely — the run is then bounded only by cooperative cancellation (Ctrl+C). A decode past its budget is stopped before the next input starts. Unlimited-OCR and the zoo models then fail that input with no text; Unlimited-OCR-2 keeps what it decoded and exits 5. |
FOCR_NO_RESIDENT |
1 or true disables the resident warm-model daemon (the flag analog is --no-resident). By default, eligible single-image focr ocr runs are served by a per-model background process that keeps the loaded weights in RAM between invocations. |
FOCR_RESIDENT_IDLE_SECS |
How long the resident daemon stays alive with no requests before unloading the model and exiting (default 600 seconds). |
FOCR_RESIDENT_DIR |
Override the directory holding resident daemon state files (default: the model cache root). |
FOCR_RESIDENT_LOG |
Append resident daemon diagnostics to this file (its stderr is discarded by default). |
FOCR_RESIDENT_SPAWN_WAIT_SECS |
How long a client waits for a freshly spawned daemon to accept (default 30). |
FOCR_RESIDENT_CLIENT_TIMEOUT_SECS |
How long a resident client waits for its reply before it runs the page inline. Set, it is a fixed wait. Unset, the client waits 600 s or until the daemon's forward stage must have ended (its budget plus the stop grace), whichever is later, so a page stopped at its budget is answered, not read again inline. With FOCR_STAGE_BUDGET_FORWARD_MS=0 it waits as long as the stage runs. |
HOME |
Required for cache resolution; the model cache installs to ~/.cache/franken_ocr/models. |
| Code | Meaning |
|---|---|
| 0 | Successful completion |
| 1 | Generic error or a not-yet-implemented surface |
| 2 | Usage or CLI argument error |
| 3 | Model artifact not found or could not be resolved |
| 4 | Input image or page could not be decoded |
| 5 | Budget, timeout or position limit exceeded, or the runaway guard stopped a v1 page (an Unlimited-OCR-2 document writes its completed pages first, and a v1 page its text so far) |
| 6 | Operation cancelled cooperatively (an Unlimited-OCR-2 document writes its completed pages first) |
| 7 | Format or version mismatch |
Unlimited-OCR is a roughly 3B-parameter Mixture-of-Experts vision-language model and a DeepSeek-OCR derivative. The forward path:
│
▼
┌──────────────────────────────────────────────────────────────────────┐
│ DeepEncoder (vision tower, kept high precision) │
│ SAM-ViT-B ──► 16x conv token compressor ──► CLIP-L/14 │
│ (SAM + CLIP features concatenate to 2048 dims) │
└──────────────────────────────────────────────────────────────────────┘
│
▼
┌──────────────────────────────────────────────────────────────────────┐
│ Linear projector 2048 ──► 1280 │
└──────────────────────────────────────────────────────────────────────┘
│
▼
┌──────────────────────────────────────────────────────────────────────┐
│ DeepSeek-V2 MoE decoder 12 layers, hidden 1280, 10 heads, hd 128 │
│ layer 0 : dense MLP │
│ layers 1..11 : MoE ── router 1280 ──► 64, top-6 of 64 experts │
│ (each expert 1280 ──► 896, SiLU-gated) │
│ + 2 always-on shared experts │
│ attention replaced by R-SWA (window 128) │
│ final RMSNorm ──► lm_head 1280 ──► 129280 │
└──────────────────────────────────────────────────────────────────────┘
│
▼
autoregressive text ──► Markdown / JSON / NDJSON
── ISA dispatch (chosen at load, one binary per arch) ──
aarch64 : NEON / SDOT / SMMLA (i8mm)
x86_64 : AVX2 / AVX-VNNI / AVX-512-VNNI
- DeepEncoder (vision tower). SAM-ViT-B, then 16x conv token compression, then a CLIP-L/14 cascade. SAM and CLIP features concatenate to 2048 dims. Kept high precision; quantizing the vision tower hurts OCR, a result both community quants confirm.
- Linear projector. A single 2048 to 1280 map bridges the vision tower to the decoder hidden size.
- DeepSeek-V2 MoE decoder. 12 layers, hidden 1280, 10 heads, head_dim 128. Layer 0 is a dense MLP; layers 1 to 11 are MoE, with a router (1280 to 64) selecting the top 6 of 64 experts (each a 1280 to 896 SiLU-gated MLP) plus 2 always-on shared experts. Final RMSNorm and
lm_head(1280 to 129280) feed autoregressive sampling. - R-SWA. The decoder's attention novelty; generated-token KV is bounded to a 128-token window while the reference block stays as a frozen, never-evicted global KV.
The upstream checkpoint is a single 6.67 GB bf16 safetensors shard under the MIT license. focr convert turns the decoder FFN/expert GEMMs into int8 inside the .focrq format and leaves the vision tower, projector, embeddings, router, and norms high precision.
For the default Unlimited-OCR runtime, point to the raw BF16 checkpoint or a locally converted artifact with the exact conservative recipe:
export FOCR_MODEL_PATH=/path/to/Unlimited-OCR
focr ocr page.pngRun focr pull to install the v0.7.0 conservative exact-recipe artifact. If a download is interrupted, rerun the command: the pull lock is process-scoped, orphan staging files are diagnosed by focr doctor, and no file becomes visible until every part and the final reassembled hash verify. A pull renames nothing into place until all of the model's files have verified. A model installed in its own directory (focr pull <model>, under models/<model>/) is replaced as one package, so its artifact and tokenizer always match. If a pull is interrupted mid-swap, the next pull of that model restores the previous package, and focr doctor reports it. focr pull --json reports each part's SHA-256 and the install outcome as NDJSON lines on stderr. Use focr models to inspect the complete model zoo.
Check what the binary detected on this host, then confirm the int8 kernel is correct:
focr robot backends # effective dense route + hardware tier/capabilities
focr robot health # model present, arch features, thread budget
focr robot selftest # int8 GEMM bit-identical to scalar oracle (exit 1 on divergence)To force a specific tier for verification, set FOCR_FORCE_ARCH (for example FOCR_FORCE_ARCH=scalar focr robot selftest).
Compatible focr pull <model> commands verify every part and the reassembled file automatically. If a manual download fails shasum -a 256 -c (or sha256sum -c), it is corrupt or truncated. A manifest, recipe, format, or version mismatch surfaces as exit code 7; do not bypass it by renaming an artifact.
Once compatible weights are installed, inference touches no network. To pin raw or locally converted Unlimited-OCR weights explicitly:
export FOCR_MODEL_PATH=/path/to/unlimited-ocr.focrq
focr ocr page.pngFOCR_MODEL_PATH accepts a .focrq blob or a safetensors directory.
The legacy all-int8 experiment can repeat on a few hard, dense tables. The v0.7.0 conservative exact-recipe artifact with exact Torch routing terminates on page0590 and clears the corpus budget with the runaway guard off, though the hard-page CER tail remains high. When reproducing the rejected legacy experiment, one mitigation is a tighter n-gram guard; it is not a release certification:
# Reproduce the gated all-int8 path with a tighter guard.
FOCR_DECODE_INT8=1 FOCR_INT8_ATTN=1 FOCR_INT8_LMHEAD=1 \
FOCR_NO_REPEAT_NGRAM=20 focr ocr hard_table.pngDrop FOCR_DECODE_INT8 to return to the conservative default. The native
all-high-precision diagnostic is explicitly stateless and quadratic:
FOCR_DECODE_STATELESS=1 \
FOCR_MODEL_PATH=/path/to/unlimited-ocr-bf16 \
focr ocr page.pngWhat this is and is not:
- Unlimited-OCR has a documented hard-page tail. The v0.7.0 exact-recipe artifact keeps attention and
lm_headhigh precision, emits EOS onpage0590, and passes the complete 20-page CER budget, butpage0590remains high at normalized CER 0.6164886. The release is hash-verified and does not claim the unavailable three-party OpenPGP certificate. For the slow native all-high-precision diagnostic, combine raw BF16 withFOCR_DECODE_STATELESS=1; raw storage alone still takes the conservative cached int8 FFN/expert route. - TrOMR int8 is default, with a documented fallback.
focr pull tromrfetches the smallertromr.int8.focrqartifact. The corpus gate stays green, but the discrepancy ledger records one degraded public-domain Spohr page where int8 and f32 diverge into different bad token streams. Usefocr pull tromr --quant f32and--model tromr.focrqwhen you need bit-exact reference behavior. - Image and PDF input. PNG, JPG, and similar, plus native PDF:
focr ocr file.pdfrasterizes pages in process (pure Rust, no FFI, no out-of-bandpdftoppm) and OCRs the document. The renderer applies page-level and image-placement rotations before OCR, so common scanned-book PDFs that display a rotated image through the content stream are not fed sideways to the model.--pageslets you run only the source pages you need, and--split-spreadscan split common two-page book scans when the gutter is clear enough. The fast path covers common scanned-PDF codecs: JPEG (DCTDecode), CCITT Group 4 fax, andFlateDecode/LZW raw rasters. Two image codecs with no production-quality pure-Rust decoder,JPXDecode(JPEG 2000) andJBIG2Decode, plus born-digital vector/text pages, are reported with a precise error naming what was unsupported. Rasterize that PDF out of band and retry. - Native Windows x86_64 is proven end-to-end; ARM64 has a narrower proof. The
x86_64-pc-windows-msvcbinary runs full OCR on real Windows 10 with the same model, vision tower, and DeepSeek-V2 decoder as macOS and Linux. The ARM64 MSVC binary builds and passes the no-weights CLI/robot smoke suite on a native hosted Windows 11 ARM runner (dist run29048523156), and the PowerShell installer selects its stable asset name. Full model OCR and installer e2e on an ARM64 Windows machine remain release-verification obligations.focr.exe robot selftestcovers the int8 GEMM scalar-oracle contract, including K=6848.focr pullperforms native multi-part download, reassembly, and SHA-256 verification. The model cache resolves to%LOCALAPPDATA%\franken_ocr\models, falling back to%USERPROFILE%\.cache\franken_ocr\models; on macOS and Linux it stays at~/.cache/franken_ocr/models. - A few models, not any model. Generality is a deliberate non-goal.
franken_ocrruns a small family of hand-ported models: Unlimited-OCR by default, GOT-OCR2 for structured formats, SmolVLM2 for image description/VQA, OneChart for chart-to-data extraction, and TrOMR for sheet-music OMR on full printed/scanned pages or staff crops. TrOCR and pix2tex remain descriptor-only roadmap items. Each ready model is transformed offline, distributed through the manifest with required sidecars, and certified against its reference before it ships. It will not become a generic inference runtime that loads arbitrary checkpoints. - Not benchmark SOTA. Unlimited-OCR is strong but not the OmniDocBench leader. The aim is fidelity to this model, bounded generated-token KV for long-document parsing on CPU, and speed on commodity hardware, not topping a benchmark.
- CPU only. No GPU. CUDA is a deferred stretch goal; CPU stays the product.
Is this affiliated with Baidu? No. It is an independent pure-Rust reimplementation that runs Baidu's openly-licensed (MIT) model weights. The weights and any quantized derivative this project distributes carry the model notice surfaced by the binary and .focrq metadata: Baidu Unlimited-OCR - Copyright (c) 2026 Baidu, MIT License.
Can it use my GPU? No. There is no CUDA, Metal, or other GPU path in the inference stack; CPU is the product, and that portability (single binary, no driver stack, runs where ort/CUDA cannot build) is the point. A CUDA backend for the int8 expert FFN and lm_head GEMMs is tracked as an explicitly deferred stretch phase, gated on bit-equivalent-where-integer parity with the CPU kernels — no timeline. If a page is slow today, work through the speed checklist.
Why use this instead of llama.cpp or ONNX? Both are excellent general runtimes. franken_ocr is a focused build: a small fixed set of hand-ported models lets the kernels specialize to each model's exact shapes and skip the generality tax. The whole thing ships as one Rust binary with no FFI and is portable to targets where ort or CUDA cannot build.
Why Rust, and why forbid unsafe? Memory safety for a multi-gigabyte weight loader and a tight decode loop, with unsafe confined to small audited islands: SIMD modules with bit-identical scalar fallbacks and the optional read-only mmap call. Owned weight bytes are the default.
Does int8 hurt accuracy? A historical real-page run measured CER 0.0094 and matched the Baidu reference decode to within one token, but that single row is not a release-wide certificate. The legacy full-int8 artifact repeats on hard dense tables. The v0.7.0 conservative exact-recipe artifact instead emits EOS on page0590 at 4,033 generated tokens and passes 20/20 pages at aggregate normalized CER 0.19307925 within the 0.25 budget; page0590 itself remains a high-tail case at CER 0.6164886. Native all-high-precision comparison requires raw BF16 plus FOCR_DECODE_STATELESS=1; the default cached route remains mixed precision.
Can it run as a server so the model loads once (like llama.cpp)? Yes — this is automatic. Eligible single-image focr ocr runs are served through a resident warm-model daemon: the first invocation spawns a per-model background process (loopback-TCP, authenticated by a user-only state file) that keeps the loaded weights in RAM, and every later invocation within the idle window (default 10 minutes, FOCR_RESIDENT_IDLE_SECS) skips the multi-gigabyte artifact load. The daemon exits by itself after the idle period, re-verifies the artifact identity on every request, and any daemon problem silently falls back to the classic in-process load — the output contract is identical. Opt out with --no-resident or FOCR_NO_RESIDENT=1. There is no HTTP API; for programmatic long-lived use, embed the library (OcrEngine caches the model for the process lifetime).
Can I embed it in my Rust program? Yes. The library API is synchronous and blocking, and the engine owns its runtime internally, so there is no async plumbing to thread through your code.
Where do the weights live, and do they ever download at inference? Compatible zoo pulls cache under ~/.cache/franken_ocr/models; raw or locally converted Unlimited weights can live anywhere and be selected with FOCR_MODEL_PATH. Weights are never bundled or downloaded during focr ocr; inference is offline.
Which binary do I download? One per architecture. The x86_64 binary covers AVX2/AVX-VNNI/AVX-512-VNNI; the aarch64 binary covers NEON/SDOT/SMMLA. The right tier is chosen at load. Or just use the curl installer and let it pick.
About Contributions: Please don't take this the wrong way, but I do not accept outside contributions for any of my projects. I simply don't have the mental bandwidth to review anything, and it's my name on the thing, so I'm responsible for any problems it causes; thus, the risk-reward is highly asymmetric from my perspective. I'd also have to worry about other "stakeholders," which seems unwise for tools I mostly make for myself for free. Feel free to submit issues, and even PRs if you want to illustrate a proposed fix, but know I won't merge them directly. Instead, I'll have Claude or Codex review submissions via gh and independently decide whether and how to address them. Bug reports in particular are welcome. Sorry if this offends, but I want to avoid wasted time and hurt feelings. I understand this isn't in sync with the prevailing open-source ethos that seeks community contributions, but it's the only way I can move at this velocity and keep my sanity.
The franken_ocr source code is licensed under the MIT License with an OpenAI/Anthropic Rider, Copyright (c) 2026 Jeffrey Emanuel.
The model weights are a separate matter. The Baidu Unlimited-OCR weights, and any quantized derivative this project distributes, are under the MIT License, Copyright (c) 2026 Baidu, reproduced in full in LICENSE under "THIRD-PARTY MODEL WEIGHTS, NOTICE". That notice travels with any distributed weight artifact.
COMPREHENSIVE_PLAN_FOR_FRANKEN_OCR.md, the master plan: architecture census, quantization format, the kernel-optimization catalog, the alien-artifact math families, the verification gauntlet, and the phased roadmap.AGENTS.md, conventions for human and agent contributors, including the engineering doctrine.CHANGELOG.md, the project history.docs/PERF_LEDGER.md, the honest measured perf-ratio log.docs/FEATURE_PARITY.md, the FeatureUniverse and SurfaceMatrix scoreboard read by the release gauntlet.docs/gauntlet/METHODOLOGY.md, the three-pillar release certification design.docs/gauntlet/RELEASE_SCORECARD.json, the current surface-pillar gauntlet scorecard artifact.docs/gauntlet/EPROCESS_STATE.json, the persisted invariant-monitor state.docs/NEGATIVE_EVIDENCE.md, what did not work, including results inherited from sibling projects.docs/DISCREPANCIES.md, known measured divergences from the reference model.docs/conformance/LADDER_HARNESS.md, the L0-L5 scorecard runner and parity-receipt contract.docs/conformance/RATCHET.md, the conformal lower-bound release ratchet.
