From @crowsonkb.
The Replicate demo runs the version from October 2022, which has none of the speedups, models or options this README measures.
Disclaimer: I'm redirecting efforts to pyglide and may be slow to address bugs here.
I also recommend looking at @crowsonkb's v-diffusion-pytorch.
See more generations, each with its command, in the Gallery.
Requires uv.
git clone https://github.com/afiaka87/clip-guided-diffusion.git
cd clip-guided-diffusion
uv syncuv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A monarch butterfly on a purple flower"
That is the classic pipeline: an ImageNet model steered by CLIP, with no extra dependencies to download. It conditions the model on the ImageNet class closest to the prompt, and prints it: monarch butterfly, here. uv run cgd -gif "A monarch butterfly on a purple flower" works too. The options were chosen by eye for a better image, and most examples here use them:
-size 256, twice the default size.-n 90, three times the default steps.-clip ViT-B/32+PE-Core-B-16, an ensemble, the one option that measurably improves the image.-gl 0.99, which holds back the part of CLIP's update that would clip, for natural colour.-freq 3, which keeps every third step, so the GIF stays small.
That took 37 s on an RTX 2070 SUPER. For the best images this repo makes, use a modern backbone, here in 48 s:
uv run cgd -bb sd-turbo -gif "A monarch butterfly on a purple flower"
Every GIF in this README is its command's real output, with the default seed. The one exception is the upscaling comparison, which is made from a command's two outputs.
- The path of the finished image is printed at the end. See Speed for how long that takes.
./outputswill contain intermediate outputs, every 10 steps by default. Change this with--save-frequency/-freq.current.pngwill contain the current generation.- The same
--seedand arguments reproduce the image byte for byte on the same machine and library versions. - Use
--gif/-gifto save a high-quality GIF of every step, at 10 frames a second, and delete the frames. The frames of the batch's first image are inoutputs/<prompt>/00/, and its GIF isoutputs/<prompt>/00.gif. - Use
--mp4/-mp4to save a high-quality MP4 of every step the same way, asoutputs/<prompt>/00.mp4. - The classic pipeline's animation shows its estimate of the finished image at each step, so it runs from a blur to the image. A backbone's shows each step of CLIP reshaping an image that is finished from the first frame, and ends on the image from the full decoder.
- Animation exports require FFmpeg. Frames stream to the encoder without buffering the whole
animation in memory. MP4 uses H.264/yuv420p, padding odd dimensions for playback compatibility.
Exports replace the destination only after successful encoding; failures preserve source
frames and any previous export. The final image remains available as
current.png. ~/.cache/clip-guided-diffusion/will contain downloaded checkpoints from OpenAI/Katherine Crowson.
- The prompt, in quotes
--image-size/-size
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A great grey owl perched on a branch"
- multiple prompts can be specified with the
|character. - you may optionally specify a weight for each prompt using a
:character. - e.g.
uv run cgd "Noun to visualize:1.0|style:0.1|location:0.1|something you dont want:-0.1" - weights must not sum to 0
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A steam locomotive crossing a stone bridge"
A negative weight takes the smoke away:
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A steam locomotive crossing a stone bridge|smoke:-0.5"
--image-prompts / -imgs take paths or URLs, and the same | and : syntax. They can replace the text prompt or add to it.
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 -imgs "images/goose_on_the_run.png"
The prompt is this goose, a generation from 2021. The ImageNet class comes from the image prompts too: goose, here.
- Using a CPU takes much longer than using a GPU. This took 145 s on a Ryzen 9 3900X, and 15 s without
--device cpuon an RTX 2070 SUPER. - The CPU runs the diffusion model at full precision, where the GPU uses half, and the same seed gives a different image on each.
uv run cgd --device cpu -gif -freq 2 -clip ViT-B/32+PE-Core-B-16 -n 60 -gl 0.99 "A wooden cabin in a snowy forest"
There's no need to specify a device: without --device, it uses CUDA whenever PyTorch can.
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A wooden cabin in a snowy forest"
--steps / -n (default: 30)
- The number of model calls. Fewer is faster.
30matches the original sampler on prompts held out from tuning.20is a third faster, but doubles the share of clipped pixels. Below15quality falls off quickly.
--guidance-rate / -rate (default: 0.08)
- The most CLIP may move the image each step, relative to the noise. Higher follows the prompt harder, but saturates and clips the image.
- Start from an image instead of pure noise.
How much of the 1000 step schedule to skip. Higher stays closer to the image. Defaults to half of it, 500.
Adds a VGG perceptual loss (LPIPS) between the image and the init image, which keeps the init's composition. 1000 seems to work well. In this example 0 sank the cap into tall grass and lost the stem, 3000 kept the fence behind the mushroom but barely turned it red, and 1000 sits between them.
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 \
--init-image images/32K_HUHD_Mushroom.png \
--init-scale 1000 \
--skip-timesteps 300 \
"A red mushroom in the grass"
The init image is this mushroom, a generation from 2021. Skipping 300 of the 1000 steps leaves 66 of the 90 model calls, so the GIF has 23 frames.
- options:
64, 128, 256, 512 pixels (square), or any multiple of 8 with--backbone - Every size runs in 8 GB of VRAM with the default CLIP model. See Speed for the time and memory each one takes, and CLIP models for the models that need more.
- Above 256x256 pixels per batch, the U-Net recomputes its activations during guidance instead of storing them. That takes about 1.5x the time per guided step and under half the memory, and it is automatic.
uv run cgd -gif --init-image images/32K_HUHD_Mushroom.png \
--skip-timesteps 500 \
--image-size 64 \
"8K HUHD Mushroom"
resized to 200 pixels for visibility
uv run cgd -gif -freq 2 -size 512 -clip ViT-B/32+PE-Core-B-16 -n 60 -gl 0.99 "A sailboat on a calm lake at sunset"
-n 60 instead of 90, because each step costs more at 512. That took 53 s.
Non-square generations
Generate portrait or landscape images by specifying a number to offset the width and/or height, with --width-offset / -wd and --height-offset / -ht.
- height and width must be multiples of an eighth of the image size: 8 at 64x64, 16 at 128x128, 32 at 256x256, 64 at 512x512. With
--backbone, any multiple of 8. - None of 12 runs from 80x64 to 640x512 produced NaN or Inf, and by eye the images were as clean as square ones.
- a positive offset will require more memory.
- a negative offset uses less memory and is faster.
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 \
--width-offset 128 \
"A castle on a hill at sunset"
--backbone / -bb
uv run cgd -bb sd-turbo -gif "A red fox in the snow"
The ImageNet models only learned ImageNet, and CLIP cannot supply what a model never learned. With -bb a modern one-step model draws the image, and CLIP corrects it by optimising the model's starting noise for 50 steps (ReNO). There is no solver to tune, the noise stays on the model's prior, and the same --seed still reproduces the image byte for byte.
-bb |
Size | Plain, -iters 0 |
With CLIP | Download | License |
|---|---|---|---|---|---|
sd-turbo (start here) |
512 (default) | 6.4 s, 2.5 GiB | 27.2 s, 3.2 GiB | 2.5 GB | Stability Community. Commercial use needs registration and ends above USD 1M revenue |
vega |
768 | 9.5 s, 2.9 GiB | 36.0 s, 3.6 GiB | 3.6 GB | Apache-2.0 |
| 1024 (default) | 9.9 s, 3.9 GiB | 49.8 s, 4.7 GiB | |||
sdxl-lightning |
768 | 10.4 s, 6.3 GiB | 57.6 s, 7.0 GiB | 12 GB | OpenRAIL++ |
| 1024 (default) | 10.2 s, 7.3 GiB | Out of memory on 8 GB |
Wall clock for one image with cgd, including startup and loading with the weights already on disk, and peak VRAM, on an RTX 2070 SUPER with 8 GB and nothing else on it. With CLIP means the defaults, ViT-B/32+PE-Core-B-16 and -aes 0.05. sdxl-lightning at its default 1024 needs -size 768 on 8 GB, or -iters 0, which skips CLIP. Even a single -clip ViT-B/32 runs out of memory there. It should fit 12 GB with CLIP, but nothing has been run on an RTX 4070. Weights go to the Hugging Face cache.
How the images score, on 12 prompts held out from tuning, 3 seeds on SD-Turbo and 4 on ADM. The first three columns are CLIP similarity to the prompt on models that did not guide the image, and the last is a predicted human rating from 1 to 10 made by a ViT-B/16 predictor that also did not guide it.
ViT-B/16 |
ViT-H-14-quickgelu |
ViT-L-16-SigLIP2-256 |
Rating | |
|---|---|---|---|---|
| Default ADM, 128 | 0.293 | 0.289 | 0.109 | 4.79 |
| ADM, 128, with an ensemble | 0.308 | 0.313 | 0.127 | 4.85 |
-bb sd-turbo -iters 0 |
0.342 | 0.373 | 0.184 | 6.48 |
-bb sd-turbo -aes 0 |
0.357 | 0.385 | 0.193 | 6.35 |
-bb sd-turbo |
0.350 | 0.384 | 0.194 | 6.90 |
The swap is by far the biggest gain measured here, over four times the best change that stays on ADM. Size explains little of it: ADM at 512 gains 0.025 ± 0.029 over ADM at 128 on one seed, against 0.081 for the swap. These models resize to about 224 pixels, so they cannot see fine detail, and no person has rated these images.
At 768, on one seed and with -aes 0.1 on the whole frame, CLIP added 0.010 to vega, which still scored 0.005 below sd-turbo at 512 and looks softer and less saturated. sdxl-lightning was the sharpest by eye, and CLIP added nothing measurable to it, so -iters 0 is its best setting unless you want the aesthetic term. At 1024 only time and memory were measured.
--iterations/-iters(default50):100takes twice as long and adds 0.002.200adds 0.006 on one seed, and starts to look adversarial.25loses 0.010.- The prompt conditions the model as well as CLIP, except for negative weights, which only CLIP sees.
Wall clock for uv run cgd, including startup and model loading, on an RTX 2070 SUPER with 8 GB:
| Size | Sampler | Model calls | Time | Peak VRAM |
|---|---|---|---|---|
| 64 | default | 30 | 4.9 s | 1.6 GiB |
| 128 | default | 30 | 6.5 s | 2.4 GiB |
| 256 | default | 30 | 11.4 s | 5.3 GiB |
| 512 | default | 30 | 22.4 s | 4.1 GiB |
| 128 | the original, since removed | 1000 | 2 min 16 s |
Quality was measured on prompts held out from tuning, as the ViT-B/16 CLIP similarity to the prompt. Guidance uses ViT-B/32, so this model is not the one being optimised.
- 128px, 12 prompts: a tie with the original 1000 step sampler, 0.292 against 0.292 (difference 95% CI -0.018 to +0.016), with fewer clipped pixels, 6% against 7%. The look is different though, and any single image is not the same image.
- The unconditional checkpoints, 256px, 6 prompts: behind the original sampler, 0.316 against 0.331 (difference 95% CI -0.040 to +0.014), and the original scored higher on 5 of the 6. With no class to bring the subject, CLIP had to set the composition too. Both were removed: the class conditional models with the fast sampler are the better trade.
The original pipeline takes 1000 ancestral steps, because CLIP has to build the whole image while the U-Net follows a random class that changes every step. The sampler in cgd/sampler.py gets there in 30 model calls:
- The U-Net is conditioned on the ImageNet class closest to your prompt, so it brings the subject and CLIP only steers.
- A second-order stochastic solver, DPM-Solver++(2M) SDE, covers the schedule in uniform logSNR steps.
- Guidance is capped relative to the noise, so it stays stable with steps 33x larger than the original's.
- Guidance only runs from 10% to 80% of the schedule, where it helps. The other steps also skip backpropagating through the U-Net, the most expensive part of guidance.
- CLIP sees 4 random cutouts. At 128px they span 70-100% of the frame, where the original's 16 cutouts were all the same full frame. At 512px they span 44-100%, because a cutout is never smaller than CLIP's 224px input. See Cutouts.
Model loading is faster too: checkpoints are memory mapped instead of copied, nothing is randomly initialised just to be overwritten, and the ImageNet class features are cached on disk.
--clip-model / -clip (default: ViT-B/32)
uv run cgd -gif -freq 3 -clip PE-Core-L-14-336 -size 256 -n 90 -gl 0.99 "A red fox in the snow"
Join models with + to guide with all of them, see Ensembles.
OpenAI's RN50, RN101, RN50x4, RN50x16, ViT-B/16, ViT-B/32 and ViT-L/14 are still there. These are the newer ones, from open_clip: Meta's PE-Core and Google's SigLIP 2.
| Model | ImageNet zero-shot | Input | Download | Load |
|---|---|---|---|---|
ViT-B/32 (default) |
63.3% | 224 | 0.3 GiB | 0.8 s |
PE-Core-B-16 |
78.4% | 224 | 1.7 GiB | 2.6 s |
ViT-L-16-SigLIP2-256 |
82.5% | 256 | 3.3 GiB | 3.9 s |
PE-Core-L-14-336 |
83.5% | 336 | 2.5 GiB | 3.9 s |
ViT-SO400M-16-SigLIP2-384 |
84.1% | 384 | 4.2 GiB | 4.7 s |
ViT-gopt-16-SigLIP2-384 |
85.0% | 384 | 7.0 GiB | 8.5 s |
PE-Core-bigG-14-448 |
85.4% | 448 | 9.0 GiB | 13.4 s |
Accuracy is as published by open_clip and Meta. Weights download to ~/.cache/clip-guided-diffusion/clip/ the first time a model is used. Loading takes about the download size in system RAM.
The first run of each model also encodes the ImageNet class names, once, on the CPU: 2 minutes for ViT-gopt-16-SigLIP2-384, 2.5 for PE-Core-bigG-14-448, on a Ryzen 9 3900X.
Use the pair ViT-B/32+PE-Core-B-16, see Ensembles. Of the single models, PE-Core-B-16 looked best: it takes the same VRAM as the default and about 1.3 s more per image, it was the only model to beat ViT-B/32 with all three judges at 128 on seed 0, and at 256 it does as well as the bigger models. Over 4 more seeds at 128 that lead shrank to a tie, +0.001 ± 0.015, so on its own it is not worth the download.
Higher ImageNet accuracy did not make a better guide. ViT-gopt-16-SigLIP2-384 and PE-Core-bigG-14-448 tie or trail the default by score, at 5x to 15x the time at 128. By eye they draw the most photographic images, which can work against the prompt: ViT-gopt-16-SigLIP2-384 at fp32 turned "a pencil sketch of an old man with a beard" into a photo of a bird. ViT-SO400M-16-SigLIP2-384 at fp32 wrote nonsense text across "a plate of sushi on a black slate".
ViT-B/32 stays the default because it is the fastest and its gradient is by far the smoothest.
Each cell is the change in CLIP similarity to the prompt against ViT-B/32, on 12 prompts held out from tuning with seed 0, then how many of the 12 improved. Three models judged the images, and a model never grades its own guidance, hence the empty cells. ViT-B/16 is close kin to ViT-B/32, so it favours it. -rate was tuned on ViT-B/32 and not retuned per model. The 95% interval on a difference is about ±0.03, so most of these are ties.
128:
| Model | Precision | ViT-B/16 |
ViT-H-14-quickgelu |
ViT-L-16-SigLIP2-256 |
|---|---|---|---|---|
PE-Core-B-16 |
fp32 | +0.014 (8) | +0.016 (10) | +0.025 (8) |
ViT-L-16-SigLIP2-256 |
fp32 | -0.019 (5) | +0.010 (5) | |
-fp16 |
-0.008 (5) | +0.007 (6) | ||
PE-Core-L-14-336 |
fp32 | -0.017 (4) | +0.001 (7) | +0.001 (5) |
-fp16 |
-0.011 (5) | +0.017 (9) | +0.011 (8) | |
ViT-SO400M-16-SigLIP2-384 |
fp32 | -0.010 (3) | +0.005 (6) | +0.017 (8) |
-fp16 |
-0.019 (4) | -0.009 (4) | -0.008 (5) | |
ViT-gopt-16-SigLIP2-384 |
fp32 | -0.025 (3) | -0.012 (6) | -0.017 (6) |
-fp16 |
-0.031 (2) | +0.004 (7) | -0.003 (7) | |
PE-Core-bigG-14-448 |
-fp16 |
-0.022 (6) | -0.001 (8) | -0.001 (7) |
256:
| Model | Precision | ViT-B/16 |
ViT-H-14-quickgelu |
ViT-L-16-SigLIP2-256 |
|---|---|---|---|---|
PE-Core-B-16 |
fp32 | -0.002 (4) | +0.018 (7) | +0.031 (12) |
PE-Core-L-14-336 |
fp32 | -0.004 (5) | +0.020 (9) | +0.032 (10) |
ViT-SO400M-16-SigLIP2-384 |
fp32 | -0.021 (3) | +0.018 (8) | +0.035 (11) |
ViT-gopt-16-SigLIP2-384 |
-fp16, 2 cutouts |
-0.041 (3) | -0.014 (5) | -0.003 (5) |
-fp16 moved scores in both directions, by less than the noise, which is why it counts as no measurable difference.
Time to sample one image and peak VRAM, the median of 3 prompts on an RTX 2070 SUPER with 8 GB and nothing else on it. Add the load time above, once per run. ~ marks a size that ran out of memory on this card: the number is what it should need, projected from the models that ran at that size, and has not been measured.
| Model | Precision | 128 | 256 | 512 |
|---|---|---|---|---|
ViT-B/32 |
2.7 s, 2.3 GiB | 7.5 s, 5.3 GiB | 18.7 s, 4.1 GiB | |
PE-Core-B-16 |
fp32 | 4.0 s, 2.4 GiB | 8.8 s, 5.3 GiB | 20.0 s, 4.1 GiB |
-fp16 |
3.3 s, 2.2 GiB | 8.2 s, 5.2 GiB | 19.4 s, 4.0 GiB | |
ViT-L-16-SigLIP2-256 |
fp32 | 7.5 s, 3.3 GiB | 12.5 s, 6.3 GiB | 23.8 s, 4.9 GiB |
-fp16 |
4.2 s, 2.6 GiB | 9.2 s, 5.6 GiB | 20.5 s, 4.4 GiB | |
PE-Core-L-14-336 |
fp32 | 16.0 s, 3.7 GiB | 20.7 s, 6.6 GiB | 32.3 s, 4.9 GiB |
-fp16 |
7.8 s, 2.8 GiB | 12.7 s, 5.8 GiB | 24.0 s, 4.4 GiB | |
ViT-SO400M-16-SigLIP2-384 |
fp32 | 19.3 s, 4.2 GiB | 24.1 s, 7.1 GiB | 35.4 s, 5.4 GiB |
-fp16 |
7.8 s, 3.1 GiB | 12.7 s, 6.0 GiB | 24.0 s, 4.6 GiB | |
ViT-gopt-16-SigLIP2-384 |
fp32 | 42.0 s, 7.2 GiB | ~10 GiB | ~8.5 GiB |
-fp16 |
13.7 s, 4.6 GiB | ~7.5 GiB | 30.0 s, 5.9 GiB | |
PE-Core-bigG-14-448 |
fp32 | ~11.5 GiB | ~14.5 GiB | ~13 GiB |
-fp16 |
35.3 s, 6.6 GiB | ~9.5 GiB | ~8 GiB |
256 needs more than 512 because 512 is the size where the U-Net starts recomputing its activations, see Image size. PyTorch holds on to about 0.1 GiB beyond the peak at 128 and 256, and up to 0.9 GiB at 512, so leave that free too.
| VRAM | What fits |
|---|---|
| 8 GB | Everything through ViT-SO400M-16-SigLIP2-384, at every size, though that one at 256 fp32 needs a nearly empty card. ViT-gopt-16-SigLIP2-384 at 128, or at 512 with -fp16. PE-Core-bigG-14-448 at 128 with -fp16. |
| 12 GB (estimated) | ViT-gopt-16-SigLIP2-384 at every size. PE-Core-bigG-14-448 at every size with -fp16. |
| 16 GB (estimated) | Everything, at every size. |
Runs the vision tower of a PE-Core or SigLIP2 model at half precision: up to 3x faster and half the CLIP VRAM. fp32 stays the default because it is the exact computation, but use -fp16 whenever time or VRAM matters: it made no measurable difference to quality, see Which one to use. It saves little on PE-Core-B-16, and that one combination has no quality measurement.
The gradient does change. Its cosine similarity to the fp32 gradient varied by model and image, over 3 images: 0.11 to 0.42 for ViT-gopt-16-SigLIP2-384, 0.19 to 0.996 for PE-Core-L-14-336, 0.83 to 0.93 for PE-Core-B-16, 0.95 to 0.9995 for ViT-L-16-SigLIP2-256 and 0.99 for ViT-SO400M-16-SigLIP2-384. That says less than it seems to, because these gradients are chaotic: noise of 1 part in 2048 on the input image, without changing the precision at all, moves the fp32 gradient to a cosine of 0.52 to 0.79 for ViT-gopt-16-SigLIP2-384 and 0.39 to 0.97 for PE-Core-L-14-336. Guidance averages over cutouts and steps, so it follows what stays consistent. ViT-B/32, by comparison, stays at 0.999 under the same noise. OpenAI's models always run at half precision, and at 0.9997 to 0.9999 lose nothing by it.
Everything here was measured against the default on 12 prompts held out from tuning, as the change in CLIP similarity to the prompt pooled over the three models above, with its 95% interval across prompts, and how many of the 12 improved. ADM at 128 over 4 seeds unless noted, and SD-Turbo at 512 over 3. A difference smaller than the interval is a tie. Options that lost were removed, see Tried and removed. -gl and -aes stay off by default but stay available, because a score is not an image: these models cannot see fine detail, and they reward caption match, not looks. Full evidence is in the report.
uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A red fox in the snow"
The one change that clearly helps ADM, and the default with -bb. Each model backpropagates on its own, so only one model's activations are in memory at a time.
| Size | Change | Default | Ensemble |
|---|---|---|---|
| 128 | +0.019 ± 0.015 (10), 4 seeds | 2.9 s, 2.3 GiB | 5.9 s, 2.7 GiB |
| 256 | +0.015 ± 0.014 (7), 2 seeds | 7.8 s, 5.3 GiB | 10.7 s, 5.6 GiB |
| 512 | +0.012 ± 0.015 (9), 1 seed | 18.8 s, 4.1 GiB | 21.6 s, 4.4 GiB |
That includes loading both models for every image, which a single cgd run only does once. PE-Core-B-16 on its own only ties (+0.001 ± 0.015), so it takes the pair. It is not the ADM default because that would change every existing seed's image, and it needs a 1.7 GiB download.
--candidates / -best
uv run cgd -best 4 -gif "A red fox in the snow"
Runs that many seeds from --seed, and reports the one that ViT-B/16 and ViT-L-16-SigLIP2-256 prefer. Here they picked seed 0, the image --seed 0 gives on its own. Each candidate's frames go in outputs/seed_<n>/, and only the pick's become a GIF or video. Takes that many times as long, and the judges run on the CPU. Picked that way and scored by ViT-H-14-quickgelu, which did not pick, against the average candidate: ADM best of 4 gains +0.015 ± 0.007 (11), or +0.025 ± 0.011 (12) with the ensemble. SD-Turbo best of 3 gains +0.005 ± 0.005 (8), so it matters much less there.
--upscale / -up
uv run cgd -gif -freq 3 -up -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A monarch butterfly on a purple flower"
Also saves a copy of the finished image 4x larger, made with Real-ESRGAN x4plus, a 64 MB download. It goes in the frames' folder, outputs/A_monarch_butterfly_on_a_purple_flower/00/0089_x4.png here, and the animation stays at the size that was sampled. The second GIF wipes between that copy and the same image enlarged 4x with plain bicubic resampling. It invents detail and cannot fix what the image got wrong. ADM at 128 plus -up ties ADM at 512 on score, -0.014 ± 0.028 (6) on one seed, for 3 s instead of 19 s and 2.3 instead of 4.1 GiB, so it is the cheap route to 512 on ADM and not a better one: direct 512 clips fewer pixels, 4.1% against 10.4%, and gets a higher predicted rating, 5.32 against 4.83. Going from 512 to 2048 takes under a second and about 2 GiB.
--aesthetic-scale / -aes (default 0.05 with -bb, otherwise 0)
uv run cgd -bb sd-turbo -aes 0.1 -gif "A red fox in the snow"
Also rewards what people rate highly, with Katherine Crowson's aesthetic predictor for ViT-B/32. The scale is per point of a rating from 1 to 10. It rates random cutouts instead of the whole frame, because cutouts raised the held-out rating more per point of score lost, on both models.
-aes |
Rating | Change in score | Saturation | Clipped pixels | |
|---|---|---|---|---|---|
-bb sd-turbo, 512 |
0 | 6.35 | 0.36 | 2.3% | |
| 0.05 (default) | 6.90 | -0.002 ± 0.004 (3) | 0.42 | 2.1% | |
| 0.1 | 7.12 | -0.011 ± 0.008 (1) | 0.45 | 1.9% | |
| 0.2 | 7.24 | -0.012 ± 0.006 (2) | 0.50 | 3.4% | |
| ADM, 128 | 0 (default) | 4.79 | 0.46 | 2.8% | |
| 0.05 | 5.27 | -0.013 ± 0.008 (1) | 0.60 | 3.8% | |
| 0.1 | 5.52 | -0.022 ± 0.009 (1) | 0.62 | 6.6% | |
| 0.2 | 5.67 | -0.047 ± 0.012 (0) | 0.66 | 6.7% |
The rating is a ViT-B/16 predictor that did not guide the image. The rating and the score pull apart, so choosing a scale means choosing between them. On SD-Turbo 0.05 costs nothing measurable, which makes it the default. By eye, on six prompts, 0.1 and 0.2 often have better light and composition than 0.05, and by 0.2 the subject can start to go: one cat's wizard hat shrank to a party hat. Try them if you care more about the look than about the prompt. On ADM every scale costs score and adds saturation and clipping, so it stays off.
CLIP sees 4 random cutouts, fixed, because that tied or beat everything tried. On ADM at 128, 8, 16, 32 and 64 cutouts scored -0.002 ± 0.009, +0.005 ± 0.011, +0.002 ± 0.007 and 0.000 ± 0.010. On 2 seeds, stratified layouts, mirrored cutouts and adding a whole frame tied, while keeping only the whole frame lost (-0.017 ± 0.010), and so did the Disco Diffusion mix of whole frame and small crops (-0.017 ± 0.010), reflect padding (-0.022 ± 0.023) and sizes that change during sampling (-0.007 to -0.012). On SD-Turbo at 512, where the idea should work best, eleven layouts all stayed within 0.007 of the default, on one seed, and the whole frame plus small crops lost a little on three (-0.003 ± 0.003). Cutout gradients are noisy, but removing the noise changes nothing, because the guidance step is capped and the model discards most of the gradient anyway.
Holds back the part of CLIP's update that would push more than this quantile of pixels out of range. At 0.99 clipped pixels fall from 2.8% to 0.6%, with natural colour: the best way to lose the CLIP look. By score it loses, -0.016 ± 0.012 (1), and with the ensemble it ties, +0.000 ± 0.016 (5).
These were options once. They tied or lost, so they went, to keep the command simple.
| What | Result | Notes |
|---|---|---|
| The ER-SDE solver | +0.004 ± 0.014 (8) | A tie alone. With the ensemble, +0.017 ± 0.008 and all 12 prompts improved: steadier, not higher |
| CLIP seeing only the denoised image | +0.002 ± 0.009 (7) | Instead of a blend of it and the noisy image. The blend without its gradient: -0.004 ± 0.011 (4) |
| Dynamic thresholding at 0.995 | -0.019 ± 0.014 (2) | No clipped pixels, but saturation fell from 0.46 to 0.20. Closer to 1 was lower still, and greyer |
| A sine guidance schedule | -0.006 ± 0.009 (4) | A rising one: -0.011 ± 0.012 (2) |
| Pushing away from the second closest class, at 0.5 | -0.007 ± 0.011 (5) | One more model call per guided step |
| Perturbed attention guidance, at 1 | -0.013 ± 0.009 (3) | One more model call per guided step |
| A contrastive loss | -0.010 ± 0.015 (3) | Also lost on SD-Turbo: -0.009 ± 0.006, on one seed |
| The second closest class | -0.013 ± 0.035 (3) | |
| Guidance through a small U-Net | -0.005 ± 0.023 (6) at 256, 2 seeds; -0.009 ± 0.022 (6) at 512, 1 seed; -0.019 ± 0.022 (2) at 128 | 5.3 to 1.9 GiB and 7.8 to 5.8 s at 256, 4.1 to 2.6 GiB and 18.8 to 11.2 s at 512 |
| A backbone backpropagating through its real decoder | 0.001 ± 0.003 | Twice the time and 1 GiB more at 512 |
| 4 model calls for a backbone's final image | -0.006, on one seed |
The CLIP guidance and TV loss scales, the number of cutouts, and the backbone's learning rate and noise penalty are fixed at the values everything here was tuned with.
Run from the repository root, so the image paths resolve.
from cgd.adm import generate
from cgd.outputs import save_gif
saved = generate(
["A volcano erupting at night"],
image_size=256,
steps=90,
guidance_limit=0.99,
clip_model="ViT-B/32+PE-Core-B-16",
save_frequency=3,
)
frames = [path for batch_index, path in saved] # Every saved step. The last is the result.
save_gif(frames, "outputs/A_volcano_erupting_at_night.gif")
These are the settings of uv run cgd -gif -freq 3 -size 256 -clip ViT-B/32+PE-Core-B-16 -n 90 -gl 0.99 "A volcano erupting at night", and the GIF is the same as that command's, byte for byte. With save_frequency=3 it has 31 frames: every third of the 90 steps, then the result. The other keyword arguments are the options' long names, with underscores, and progress=False is --quiet.
cgd.backbone.generate() is the same with a backbone. With the same settings it makes the same image as the command, byte for byte, so this is the GIF from Modern backbones again:
from cgd.backbone import generate
from cgd.outputs import save_gif
frames = [path for batch_index, path in generate(["A red fox in the snow"], backbone="sd-turbo", save_frequency=1)]
save_gif(frames, "outputs/A_red_fox_in_the_snow_sd-turbo.gif")
usage: cgd [-h] [-imgs IMAGE_PROMPTS] [-size IMAGE_SIZE] [-wd WIDTH_OFFSET]
[-ht HEIGHT_OFFSET] [-bs BATCH_SIZE] [-seed SEED]
[-clip CLIP_MODEL] [-fp16] [-aes AESTHETIC_SCALE]
[-best CANDIDATES] [-dev DEVICE] [-n STEPS] [-rate GUIDANCE_RATE]
[-gl GUIDANCE_LIMIT] [-init INIT_IMAGE] [-skip SKIP_TIMESTEPS]
[-is INIT_SCALE] [-bb {sd-turbo,vega,sdxl-lightning}]
[-iters ITERATIONS] [-dir OUTPUT_DIR] [-freq SAVE_FREQUENCY] [-gif]
[-mp4] [-up] [-q]
[prompts]
cgd: make images from text and image prompts with CLIP guided diffusion.
positional arguments:
prompts Text prompts, joined with |. Each can take a weight,
negative to avoid it: 'a fox:2|blurry:-1'.
options:
-h, --help show this help message and exit
-imgs, --image-prompts IMAGE_PROMPTS
Image prompts, paths or URLs, joined with | and
weighted the same way.
-size, --image-size IMAGE_SIZE
Image size. 64, 128, 256 or 512, default 128. With
--backbone, any multiple of 8, defaulting to what the
model was trained for.
-wd, --width-offset WIDTH_OFFSET
Make the image this much wider. Default 0.
-ht, --height-offset HEIGHT_OFFSET
Make the image this much taller. Default 0.
-bs, --batch-size BATCH_SIZE
Images to make at once. Default 1.
-seed, --seed SEED Random seed. Default 0.
-clip, --clip-model CLIP_MODEL
CLIP model to guide with, one of ViT-B/16, ViT-B/32,
RN50, RN101, RN50x4, RN50x16, ViT-L/14,
ViT-L/14@336px, PE-Core-B-16, ViT-L-16-SigLIP2-256,
PE-Core-L-14-336, ViT-SO400M-16-SigLIP2-384, ViT-
gopt-16-SigLIP2-384, PE-Core-bigG-14-448, or a
checkpoint file. Join several with + to guide with all
of them. Default ViT-B/32, or ViT-B/32+PE-Core-B-16
with --backbone. The README has what each costs.
-fp16, --clip-fp16 Run a PE-Core or SigLIP2 model at half precision: up
to 3x faster for half the CLIP VRAM. Less exact, but
it scored about the same. OpenAI's models always do.
-aes, --aesthetic-scale AESTHETIC_SCALE
Also reward what people rate highly, per point of a 1
to 10 rating. Default 0, or 0.05 with --backbone. The
README has what it trades away.
-best, --candidates CANDIDATES
Make this many images from seeds counting up from
--seed, and keep the one that CLIP models which did
not guide them score best. Takes this many times as
long. Default 1.
-dev, --device DEVICE
cpu, cuda or cuda:<index>. Default cuda when there is
a GPU.
ImageNet model:
The default pipeline: CLIP guides OpenAI's ImageNet diffusion model.
-n, --steps STEPS Model calls. Default 30.
-rate, --guidance-rate GUIDANCE_RATE
Guidance strength: the most CLIP may move each step,
relative to the noise. Higher follows the prompt
harder but saturates. Default 0.08.
-gl, --guidance-limit GUIDANCE_LIMIT
Hold back whatever part of CLIP's update would push
more than this quantile of pixels out of range, e.g.
0.99. Natural colour and almost no clipped pixels,
though the judges prefer the saturated default.
-init, --init-image INIT_IMAGE
Start from this image, a path or URL, instead of pure
noise.
-skip, --skip-timesteps SKIP_TIMESTEPS
How much of the 1000 step schedule an init image
skips. Higher stays closer to it. Default 500.
-is, --init-scale INIT_SCALE
Also keep the image perceptually close to the init
image, by LPIPS, e.g. 1000. Default 0.
Modern backbones:
Draw with a one-step model and correct it with CLIP by optimising its
noise, instead of guiding the ImageNet model. The best images this makes.
-bb, --backbone {sd-turbo,vega,sdxl-lightning}
The model to draw with.
-iters, --iterations ITERATIONS
Steps of noise optimisation. 0 is the plain model.
Default 50.
Output:
-dir, --output-dir OUTPUT_DIR
Where images go, in a folder named after the prompts.
Default outputs.
-freq, --save-frequency SAVE_FREQUENCY
Save a frame every this many steps. The result is
always saved. Default 10, or 1 with --gif or --mp4.
-gif, --gif Also save the frames as a GIF, then delete them.
-mp4, --mp4 Also save the frames as an H.264 video, then delete
them.
-up, --upscale Also save a copy 4x larger, made with Real-ESRGAN
x4plus. Adds little time or VRAM.
-q, --quiet No progress bars or status messages.git clone https://github.com/afiaka87/clip-guided-diffusion.git
cd clip-guided-diffusion
uv syncuv run pytest tests/unit # Seconds, on the CPU.
uv run pytest # Everything.tests/unitchecks the pure parts on small inputs: the sampler on data whose exact answer is known, the cutouts, losses, the noise optimisation, tiling, prompts and the command line.tests/integrationruns the real models on a GPU, and skips without one. Give them a free one: they fail with a genuine out of memory error if another process holds the VRAM.uv run ruff check,uv run ruff format --checkanduv run pylint cgd testsshould all pass.
