FlashAttention (Metal Port)
| Date | Stars |
|---|---|
| 2026-07-24 | 611 |
| 2026-07-25 | 611 |
| 2026-07-28 | 611 |
| 2026-07-30 | 611 |
| 2026-08-06 | 611 |
Today
— stars today
This week
— stars this week
This month
— stars this month
Momentum
0.0
growth rate 0.00%/day
# FlashAttention (Metal Port) This repository ports the official implementation of [FlashAttention](https://github.com/Dao-AILab/flash-attention) to Apple silicon. It is a minimal, maintainable set of source files that reproduces the FlashAttention algorithm. ## Documentation Single-headed attention only, to focus on the core bottlenecks of different attention algorithms (register pressure, parallelism). With the basic algorithm done correctly, it should be comparatively trivial to add customizations like block sparsity. Everything is JIT compiled at runtime. This contrasts with the previous implementation, which relied on an executable embedded in Xcode 14.2. The backward pass uses less memory than [Dao-AILab/flash-attention](https://github.com/Dao-AILab/flash-attention). The official implementation allocates scratch space for atomics and partial sums. Apple hardware lacks native FP32 atomics (`metal::atomic<float>` is emulated). While attempting to circumvent the lack of hardware support, bandwidth and parallelization bottlenecks in the FlashAttention-2 backward kernel were revealed. An alternative backward pass was designed with higher compute cost (7 GEMMs instead of 5 GEMMs). It achieves 100% parallelization efficiency across both the row and column dimensions of the attention matrix. Most importantly, it is easier to code and maintain. A lot of crazy stuff was done to overcome register pressure bottlenecks. At large head dimensions (e.g. 256), none of the matrix blocks can fit into registers. Not even the accumulator can. Therefore, intentional register spilling is done, but in a more optimized way. A third block dimension was added to the attention algorithm, which blocks along `D`. The aspect ratio of attention matrix blocks was warped heavily, to minimize the bandwidth cost of register spilling. For example, 16-32 along the parallelization dimension and 80-128 along the traversal dimension. There is a large parameter file that takes the `D` dimension, and determines which operands can fit into registers. It then assigns a block size that balances many competing bottlenecks. The end result is a consistent 4400 gigainstructions per second on M1 Max (83% ALU utilization), at infinite sequence length and infinite head dimension. Provided BF16 emulation is being used for mixed precision (Metal's `bfloat` has IEEE-compliant rounding, a major overhead on older chips without hardware BF16).   Raw Data: https://docs.google.com/spreadsheets/d/1Xf4jrJ7e19I32J1IWIekGE9uMFTeZKoOpQ6hlUoh-xY/edit?usp=sharing ## Quantifying Performance In the AI field, performance is most often reported in giga-floating point operations per second (GFLOPS). This metric reflects a simplified model of performance, that every instruction occurs in GEMM. As hardware has advanced from early FPUs to modern vector processors, the most common floating-point operations were fused into a single instruction. Fused multiply-add (FMA). When one multiplies two 100x100 matrices, 1 million FMA instructions are issued. Why must we treat this FMA as two separate instructions? This question is relevant to attention, where not all floating point operations are created equal. The exponentiation during softmax occurs in a single clock cycle, granted that most of the other instructions go to the FMA unit. Some of the multiplies and adds during softmax, cannot be fused with a nearby add or multiply. Should we treat these the same as FMA, and pretend the hardware is just executing the FMA two times slower? It is unclear how the GEMM performance model can explain whether my shader is using the ALU hardware effectively. Instead of gigaflops, I use gigainstructions to understand how well the shader is performing. It maps more directly to the algorithm. For example, one GEMM is `N^3` FMA instructions. Forward attention performs two matrix multiplies, or `2 * D * N^2` F
Excerpt of 14,396 characters
Read on GitHub
