Towards More Capable and Generalizable Embodied Foundation Models
💫 Project Page | 🤗 Hugging Face | 🤖 ModelScope | 📚 Cookbooks | 📄 arXiv | 📄 1.1 paper
- [2026.07.16] ✨✨ Release RynnBrain 1.1 checkpoints (2B / 9B / 122B-A10B) on Hugging Face & ModelScope!
- [2026.07.16] ✨✨ Release RynnBrain 1.1 Technical Report !
- [2026.07.16] ✨✨ Release RynnBrain 1.1! To access the resources of RynnBrain 1.0, please checkout to the rynnbrain1.0 branch.
- [2026.04.13] 🔥🔥 Launch RynnBrain-4B !!
- [2026.02.17] 🔥🔥 Release RynnBrain 1.0 Technical Report !!
- [2026.02.09] 🔥🔥 Release code and model checkpoints of RynnBrain 1.0!!
We present RynnBrain 1.1, a systematic upgrade of RynnBrain for embodied intelligence. RynnBrain 1.1 is released in three scales: 2B, 9B, and 122B-A10B, extending the model family from compact dense models to its first 122B-level sparse-MoE model.
- Unified Embodied Scaling to 122B: Establishes the first embodied brain model at the 122B scale under a unified training recipe shared across 2B, 9B, and 122B-A10B, enabling a systematic study of how embodied cognition, spatial reasoning, grounding, and planning evolve with scale.
- Native 3D and contact point grounding: Introduces explicit 3D-grounded training and a new contact point prediction task, extending RynnBrain from image-plane localization to metric 3D understanding and action-relevant interaction grounding.
- Real-robot VLA transfer: Bridges perception and action through RynnBrain-VLA, translating embodied understanding into real-robot control and demonstrating strong cross-platform generalization on Unitree G1, Astribot, and Tianji-Wuji across humanoid, bimanual, and dexterous-hand tasks.
RynnBrain 1.1 adopts a unified decoder-only vision-language architecture across all scales, supporting both dense and sparse-MoE variants. It encodes omni-vision inputs with language instructions and produces aligned outputs — text, pointing sequences, 3D perception, and contact signals — enabling egocentric understanding, spatio-temporal grounding, physical-world reasoning, and fine-grained planning.
- General Embodied Understanding
RynnBrain 1.1-2B vs. other 2B-scale models
RynnBrain 1.1-9B vs. other 9B-scale models
RynnBrain 1.1-122B vs. other 122B-scale models
- Real-Robot VLA Evaluation
Real-robot VLA success rates vs. baselines
Real-robot deployment demos
- 3D Grounding
3D grounding accuracy vs. baselines
- Contact Point Prediction
Contact point prediction visualization
| Model | Base Model | HuggingFace | ModelScope |
|---|---|---|---|
| RynnBrain1.1-2B | Qwen3.5-2B | Link | Link |
| RynnBrain1.1-9B | Qwen3.5-9B | Link | Link |
| RynnBrain1.1-122B-A10B | Qwen3.5-122B-A10B | Link | Link |
Minimal dependencies
pip install transformers==5.2.0Run text generation
import torch
from transformers import AutoModelForImageTextToText, AutoProcessor
conversation = [
{
"role": "user",
"content": [
{"type": "image", "image": "cookbooks/assets/object_location/images/000000086408.jpg"},
{
"type": "text",
"text": "What appliance can be used to heat food quickly.\nGenerate coordinates for one object bounding box. Constraints: x1,y1,x2,y2 in [0,1000]. Response must be in the format: <object> (x1, y1), (x2, y2) </object>",
},
],
}
]
model_path = "Alibaba-DAMO-Academy/RynnBrain1.1-2B"
processor = AutoProcessor.from_pretrained(model_path)
model = AutoModelForImageTextToText.from_pretrained(
model_path,
dtype=torch.bfloat16,
)
model.to("cuda")
model_inputs = processor.apply_chat_template(
conversation,
add_generation_prompt=True,
enable_thinking=False,
tokenize=True,
return_dict=True,
return_tensors="pt",
)
model_inputs = model_inputs.to("cuda")
output_ids = model.generate(
**model_inputs,
max_new_tokens=256,
do_sample=False,
)
output_ids = output_ids[:, model_inputs["input_ids"].size(1) :]
response = processor.decode(output_ids[0], skip_special_tokens=True)
print(response)For installation and advanced usages, please refer to the official documentation.
OpenAI-Compatible Serving
# launch server
python3 -m sglang.launch_server --model-path Alibaba-DAMO-Academy/RynnBrain1.1-2B --host 0.0.0.0 --port 8000# inference using openai api
import base64
import io
from openai import OpenAI
from PIL import Image
def pil_to_url(image: Image.Image):
image_format = image.format if image.format else 'PNG'
buffered = io.BytesIO()
image.save(buffered, format=image_format)
img_str = base64.b64encode(buffered.getvalue()).decode('utf-8')
messages = [
{
'role': 'user',
'content': [
{'type': 'image_url', 'image_url': {'url': pil_to_url(Image.open('cookbooks/assets/object_location/images/000000086408.jpg'))}},
{'type': 'text', 'text': 'What appliance can be used to heat food quickly.\nGenerate coordinates for one object bounding box. Constraints: x1,y1,x2,y2 ∈ [0,1000]. Response must be in the format: <object> (x1, y1), (x2, y2) </object>'},
],
}
]
client = OpenAI(api_key="", base_url="http://localhost:8000/v1")
response = client.chat.completions.create(
model="default",
messages=messages,
stream=False,
).choices[0].message.content
print(response)Offline Engine
import sglang as sgl
from transformers import AutoProcessor
def main():
conversation = [
{
'role': 'user',
'content': [
{'type': 'image'},
{'type': 'text', 'text': 'What appliance can be used to heat food quickly.\nGenerate coordinates for one object bounding box. Constraints: x1,y1,x2,y2 ∈ [0,1000]. Response must be in the format: <object> (x1, y1), (x2, y2) </object>'},
],
}
]
model_path = 'Alibaba-DAMO-Academy/RynnBrain1.1-2B'
llm = sgl.Engine(model_path=model_path)
processor = AutoProcessor.from_pretrained(model_path)
prompt = processor.apply_chat_template(
conversation,
add_generation_prompt=True,
enable_thinking=False,
tokenize=False,
)
output = llm.generate(
prompt=prompt,
image_data='cookbooks/assets/object_location/images/000000086408.jpg',
sampling_params={"temperature": 0.8, "top_p": 0.95},
)
print(f"Prompt: {prompt}\nGenerated text: {output['text']}")
if __name__ == '__main__':
main()Check out the cookbooks that showcase RynnBrain's capabilities in cognition, localization, reasoning, and planning.
| Category | Cookbook name | Description |
|---|---|---|
| Spatial Understanding | 1_spatial_understanding.ipynb | Shows the model's ability for spatial understanding in the video scene. |
| Object Understanding | 2_object_understanding.ipynb | Shows how the model understands object categories, attributes, and relations and counting ability. |
| Object Grounding | 3_object_grounding.ipynb | Locates specific objects with bounding boxes in an image or video based on instructions. |
| Area Location | 4_area_location.ipynb | Identifies and marks specified regions by points in an image or video. |
| Affordance Location | 5_affordance_location.ipynb | Finds areas or objects with specific affordances in an image or video. |
| Trajectory Location | 6_trajectory_location.ipynb | Infers and annotates trajectories or motion paths in an image or video. |
| 🆕 Contact Point Prediction | 7_contact_point_prediction.ipynb | Predicts an instruction-conditioned contact point and in-plane orientation from an image. |
| 🆕 3D Grounding | 8_3d_grounding.ipynb | Predicts 3D bounding boxes (position, dimensions, orientation) from a single RGB image with camera intrinsics. |
Pretraining & Evaluation
Please refer to RynnScale for details of pretraining and evaluation.
Note that thinking mode is disabled by default for all benchmarks, unless otherwise specified.
Finetuning recipes and the benchmark introduced with RynnBrain 1.0, which remain fully compatible with the base model.
Finetuning
-
Reasoning: An interleaved reasoning approach that fuses spatial grounding with textual cues directly over egocentric video streams, bridging the gap between language and the physical world to keep reasoning firmly grounded in reality.
-
Navigation: A vision-language navigation model fine-tuned on the RynnBrain base model. Empirically, fine-tuning on RynnBrain yields consistently stronger navigation performance than fine-tuning on other foundation models.
-
Planning: RynnBrain embeds the locations of affordances, areas, and objects directly into its planning outputs, allowing even highly intricate, fine-grained tasks to be handled within our hierarchical RynnBrain-VLA system.
RynnBrain-Bench
RynnBrain-Bench is a high-dimensional benchmark for embodied understanding, evaluating models across four key dimensions—object cognition, spatial cognition, grounding, and pointing—with an emphasis on fine-grained understanding and spatio-temporal localization over episodic video sequences. For details, please refer to RynnBrain-Bench.
If you find RynnBrain useful for your research and applications, please cite using this BibTeX:
@article{damo2026rynnbrain,
title={RynnBrain: Open Embodied Foundation Models},
author={Ronghao Dang, Jiayan Guo, Bohan Hou, Sicong Leng, Kehan Li, Xin Li, Jiangpin Liu, Yunxuan Mao, Zhikai Wang, Yuqian Yuan, Minghao Zhu, Xiao Lin, Yang Bai, Qian Jiang, Yaxi Zhao, Minghua Zeng, Junlong Gao, Yuming Jiang, Jun Cen, Siteng Huang, Liuyi Wang, Wenqiao Zhang, Chengju Liu, Jianfei Yang, Shijian Lu, Deli Zhao},
journal={arXiv preprint arXiv:2602.14979v1},
year={2026},
url = {https://arxiv.org/abs/2602.14979v1}
}
@article{damo2026rynnbrain11,
title={RynnBrain 1.1: Towards More Capable and Generalizable Embodied Foundation Model},
author={Kehan Li, Bohan Hou, Minghao Zhu, Tianyi Zhang, Zesen Cheng, Zhikai Wang, Sicong Leng, Xin Li, Xiao Lin, Biying Yao, Minghua Zeng, Jiangpin Liu, Ronghao Dang, Jiayan Guo, Siteng Huang, Haoyu Zhao, Heng Ping, Yaxi Zhao, Kexiang Wang, Tong Lu, Shengke Xue, Jiahao Tang, Yulei Wang, Zejing Wang, Jianwei Gao, Shijian Lu, Chengju Liu, Jianfei Yang, Mingxiu Chen, Deli Zhao},
journal={arXiv preprint arXiv:2607.17977},
year={2026},
url = {https://arxiv.org/abs/2607.17977}
}💡 Some other multimodal-LLM projects from our team may interest you ✨.
RynnEC: Bringing MLLMs into Embodied World
Ronghao Dang*, Yuqian Yuan*, Yunxuan Mao*, Kehan Li*, Jiangpin Liu, Zhikai Wang, Fan Wang, Deli Zhao, Xin Li
RynnScale
RynnScale Team
RynnWorld-4D: 4D Embodied World Models for Robotic Manipulation
Haoyu Zhao, Xingyue Zhao, Siteng Huang, Xin Li, Deli Zhao, Zhongyu Li
RynnWorld-Teleop: An Action-Conditioned World Model for Digital Teleoperation
Haoyu Zhao, Xingyue Zhao, Hangyu Li, Biao Gong, Kehan Li, Siteng Huang, Xin Li, Deli Zhao, Zhongyu Li
RynnVLA-001: Using Human Demonstrations to Improve Robot Manipulation
Yuming Jiang, Siteng Huang, Shengke Xue, Yaxi Zhao, Jun Cen, Sicong Leng, Kehan Li, Jiayan Guo, Kexiang Wang, Mingxiu Chen, Fan Wang, Deli Zhao, Xin Li
RynnVLA-002: A Unified Vision-Language-Action and World Model
Jun Cen, Siteng Huang, Yuqian Yuan, Kehan Li, Hangjie Yuan, Chaohui Yu, Yuming Jiang, Jiayan Guo, Xin Li, Hao Luo, Fan Wang, Deli Zhao, Hao Chen
RynnRCP: Open Robotics Context Protocol and RobotMotion
RynnBot Team
RynnMotion: All-In-One Toolkit for Fast Robot Prototyping and Heterogeneous Teleoperation
RynnBot Team
Our RynnBrain is built on top of Qwen3-VL and Qwen3.5. We also learned a lot from the implementation of pi 0.5 and RTC. If your work is used in RynnBrain but not mentioned in either this repo or the technical report, feel free to let us know ❤️.
This project is licensed under the Apache License 2.0 - see the LICENSE file for details.
